Model

Items Spec. and parameter

BS100

BS101

BS201

BS202

BS203

Order No.

Eyepieces

WF10X/ø18

●

●

●●

●●

●●

EP10f

WF16X/ø10

○

○

○○

○○

○○

EP16c

WF10X/ø 18 (pointer)

○

○

○

○

○

Epg10a

Achromatic Objectives

Achromatic Objective 4X/0.10

●

●

●

○

○

B-OA4d

Achromatic Objective 10X/0.25

●

●

●

○

○

B-OA10e

Achromatic Objective (S) 40X/0.65

●

●

●

○

○

B-OA40e

Achromatic Objective (S) 100X/1.25(oil)

●

●

●

○

○

B-OAo100d

Plan Achromatic

Objectives

Plan Achromatic Objectives 4X/0.10

○

○

○

●

●

B-OSP4a

Plan Achromatic Objectives 10X/0.25

○

○

○

●

●

B-OSP10b

Plan Achromatic Objectives (S) 40X/0.65

○

○

○

●

●

B-OSP40f

Plan Achromatic Objectives (S) 100X/1.25(oil)

○

○

○

●

●

B-OSPo100b

Head

Monocular Head: Inclined 45° Rotatable 360°,

Interpupilary Distance: 53-75mm

●

●

TM20

Sliding Binocular Head: Inclined 45°,

Rotatable 360°, Interpupilary Distance: 52-75mm

●

●

TB12

Seidentopf binocular head, Inclined 30°,

Rotatable 360°, Interpupilary Distance: 52-75mm

●

TBR17

Main Body

Quadruple Nose piece, Coaxial Coarse and

Fine Focusing Knobs Natural Light

●

A14a

Quadruple Nose piece, Coaxial Coarse and

Fine Focusing Knobs

●

●

●

A14

Quadruple Nose piece, Coaxial Coarse and

Fine Focusing Knobs Auxiliary Lens Built-in Body

●

A14b

Stage

Mechanical stage: size: 135×130, moving

range:75×50

●

●

●

●

●

S31a

Condenser

Abbe N.A.1.25

●

●

●

●

●

C27

Mirror

Inserted

○

○

○

○

MT07

Fixed

●

MT07a

Collector

●

●

●

●

●

COL03

Base

Halogen Tungsten Lamp: 6V/20W, wide voltage input

●

●

●

●

 B32

LED: 0.5W, wide voltage input

○

○

○

○

B32b

LED (chargeable): 0.5W, wide voltage input

○

○

○

○

 B32c
