TOT-3 Series Stereo Microscope |
|
Technical Specification: |
|
Zoom Ratio1∶6.6 |
|
Magnification7×～46× |
|
Objective Zoom Range0.7×～4.6× |
|
10×Eyepiece 10×/Φ22mmhigh point (with eyecup) |
|
Standard Working Distance:110mm |
|
Interpupillary Distance54mm～76mm |
|
Observing Tube Binocular/Trinocular/built-in digital camera 45°inclined, 360°rotatable. |
|
Up Illumination 3W LED （optional :12V/15W halogen） |
|
Down Illumination 3W LED （optional :12V/15W halogen） |
|
Optional Eyepiece 15×/Φ17mm, 20×/Φ13mm |
|
Additional Objective 0.5×W.D.189mm 0.75×W.D.122mm 2×W.D.36mm |
|
TOT-3DM320/500 Built-in Digital Camera Microscope Performance |
|
Dustproof、damp proof、prevent disassembling built-in chip integrative design |
|
Light distribution 20:80, eyepiece observation synchronized with computer imaging without switching. |
|
Built-in 3MP/5MP Digital camera system,1/2’’CMOS color sequential scanning . |
|
USB2.0 connection, without external power supply. |
|
MIC image analysis software , Available for WINDOWS 2000/XP/Vistasystem. |
Magnification:
|
Additional Objectives |
0.5× |
0.75× |
1×(Built in) |
2× |
|
|
W.D. |
189mm |
122mm |
110mm |
36mm |
|
|
10×/Φ22 mm |
Magnification |
3.5～23 |
5.25～34.5 |
7～46 |
14～92 |
|
Field Dia.（mm） |
62.86～9.57 |
41.90～6.38 |
31.43～4.78 |
15.71～2.39 |
|
|
15×/Φ16 mm |
Magnification |
5.25～34.5 |
7.88～51.75 |
10.5～69 |
21～138 |
|
Field Dia（mm） |
48.57～7.39 |
32.38～4.93 |
24.29～3.70 |
12.14～1.85 |
|
|
20×/Φ13 mm |
Magnification |
7～46 |
10.5～69 |
14～92 |
27～184 |
|
Field Dia.（mm） |
37.14～5.65 |
24.76～3.77 |
18.57～2.83 |
9.29 ～1.41 |
|
TOT-3 Series Zoom Stereo Microscope outfits:
|
Items |
TOT-3BP |
TOT-3B2L |
TOT-3TP |
TOT-3T2L |
TOT-3DM320 |
|
Binocular |
● |
● |
|
|
|
|
Trinocular |
|
|
● |
● |
|
|
Digital head |
|
|
|
|
● |
|
Eyepiece 10X/Φ22mm |
●● |
●● |
●● |
●● |
●● |
|
Focusing unit |
● |
● |
● |
● |
● |
|
No light |
● |
|
● |
|
○ |
|
Reflecting 3W LED |
|
● |
|
● |
● |
|
Transmitting 3W LED |
|
● |
|
● |
● |
|
Black & white Plate |
● |
● |
● |
● |
● |
|
Glass Plate |
|
● |
|
● |
● |
|
Pillar stand |
● |
● |
● |
● |
○ |
|
Arm stand |
○ |
○ |
○ |
○ |
|
|
Reflector base |
○ |
○ |
○ |
○ |
○ |
|
Rectangular big base (330×300mm) |
○ |
○ |
○ |
○ |
○ |
|
C-mount 0.35X, 0.5X, 0.7X |
|
|
○ |
○ |
|
|
Adaptor for digital photo camera |
|
|
○ |
○ |
|
|
0.5X/0.75X/2X Objective |
○ |
○ |
○ |
○ |
○ |
|
15X/20X Eyepiece |
○ |
○ |
○ |
○ |
○ |
|
Stage Micrometer |
○ |
○ |
○ |
○ |
● |
|
Two dimensional travelling table |
○ |
○ |
○ |
○ |
○ |
|
Single pole Universal Stand |
○ |
○ |
○ |
○ |
○ |
|
Double-pole Universal Stand |
○ |
○ |
○ |
○ |
○ |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design
change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
