Specification

XSZ-158

Viewing head

Compensation Free Binocular Head,Inclined adjustment 0 ° -40 °

●

Compensation Free Trinocular Head ,Inclined adjustment 0 ° -40 °

○

Interpupillary Distance

55mm -75mm

●

Eyepiece

WF10X/22mm

●

WF16X,WF20X,WF25X,P16X

○

Nosepiece

Quintuple nosepiece

●

Sextuple nosepiece

○

Objective

Infinity plan objectives:4X,10X,40X(S),100X(S) Oil

●

Infinity plan objectives:20X(S),60X(S)

○

Stage

Double layers mechanical stage

●

Stage size:180mmX160mm

Moving range :75mmX50mm

Condenser

Swing type N.A.1.25Abbe condenser with iris  diaphragm&filter

●

Focusing

Coaxial coarse&fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value0.002mm

●

Collector

Kohler illumination

●

Light source

Halogen bulb12V/30W 12V/50W or 12V/100W.AC85-230V

●

Adjustable brightness

Optional Accessory

Fluorescent attachment

○

Phase contrast attachment

○

Dry&Immersion dark field condenser

○

Simple polarization attachment

○

3.0or1.3Mega pixel, CMOS electronic eyepiece

○
