Model |
MIC-C1400 USB3.0 |
|
Sensor Type |
1/2.3" color CMOS |
|
Pixel |
4384H*3288V(14M) |
|
Resolution and frame rate |
4384*3288:12 fps |
|
2592*1944(ROI):32 fps |
|
|
2048*1536(BIN): 28 fps |
|
|
1920×1080（BIN）：38 fps |
|
|
1920×1080（ROI）：71 fps |
|
|
1024*768（ROI）: 102 fps |
|
|
800*600（SUM）: 64 fps |
|
|
Any size ROI |
|
|
Pixels Size |
1.4μm×1.4μm |
|
Scan Mode |
Progressive scan |
|
Shutter Mode |
Electronic Rolling Shutter |
|
Exposure Time |
0.025~1000ms |
|
Image data format |
8bit/10bit/12bit |
|
Sensitivity |
0.724V/Lux-sec (550nm) |
|
spectral response |
400nm-650nm(with IR-filter) |
|
SNR |
35.5dB |
|
Dynamic Range |
65.3dB |
|
Definition |
1600-1700 line |
|
ISP |
Inner fixed |
|
Exposure control |
Manual/auto/area exposure |
|
White Balance |
Manual White Balance/ one time White Balance/ area White Balance |
|
Hardware upgrade |
Remote upgrade |
|
Camera ID |
Support customer ID input |
|
Picture format |
RAW、BMP、JPG、PNG |
|
Programming control |
Camera working speed, picture size, format, brightness, exposure time, contrast, RGB plus, arc strobe, GAMMA, RGB plus, saturation, black balance, sharpness |
|
System |
Windows XP(32); Win7(32/64) ; Win8(32/64) |
|
Software interface |
TWAIN，Direct Show |
|
Data interface |
USB3.0 5Gbps |
|
Camera hint |
LED light on, flash for working |
|
Capacity |
Less than 3.8W |
|
Power supply |
USB5V |
|
Working Temperature |
0℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Working humidity |
10%-90%RH |
|
Storage humidity |
10%-60%RH |
|
Lens interface |
C |
|
Size |
90*100.8*48.7mm |
|
Weight |
About530g |
|
Model |
MIC-C500 USB3.0 |
|
Sensor Type |
1/2.5" color CMOS |
|
Pixel |
2592H×1944V（5M） |
|
Resolution and frame rate |
2592×1944：14 fps |
|
1920×1080（ROI）：30 fps |
|
|
1024×768（ROI）：45 fps |
|
|
1280×960（SUM）：36 fps |
|
|
1280×960（BIN）：36 fps |
|
|
640×480（BIN）：55 fps |
|
|
640×480（SUM）：55 fps |
|
|
Any size ROI |
|
|
Pixels Size |
2.2μm×2.2μm |
|
Scan Mode |
Progressive scan |
|
Shutter Mode |
Electronic Rolling Shutter |
|
Exposure Time |
0.036~300ms |
|
Image data format |
8bit/10bit/12bit |
|
Sensitivity |
1.76V/Lux-sec(550nm) |
|
SNR |
38.5dB |
|
Dynamic Range |
67.7dB |
|
Definition |
1100-1200 line |
|
ISP |
Inner fixed |
|
Exposure control |
Manual/auto/area exposure |
|
White Balance |
Manual White Balance/one time White Balance/area White Balance |
|
Hardware upgrade |
Remote upgrade |
|
Camera ID |
Support customer ID input |
|
Picture format |
RAW、BMP、JPG、PNG |
|
Programming control |
Camera working speed, picture size, format, brightness, exposure time, contrast, RGB plus, arc strobe, GAMMA, RGB plus, saturation, black balance, sharpness |
|
System |
Windows XP(32/64); Win7(32/64) |
|
Software interface |
TWAIN，Direct Show |
|
Data interface |
USB3.0 5Gbps |
|
Camera hint |
LED light on, flash for working |
|
Capacity |
Less than 2.5W when working , stand by about1.5W |
|
Power supply |
USB5V |
|
Working Temperature |
0℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Working humidity |
10%-90%RH |
|
Storage humidity |
10%-60%RH |
|
Lens interface |
C |
|
Size |
90×100.8×48.7mm |
|
Weight |
About530g |
|
Model |
MIC-C1000 USB2.0 |
|
Sensor type |
1/2.3" color CMOS |
|
Pixel |
3664×2748(10M) |
|
Resolution and frame rate |
3664×2748: 4FPS |
|
1832×1372(BIN): 16.5FPS |
|
|
1920×1080(ROI): 20FPS |
|
|
1280×720(BIN): 42FPS |
|
|
916×688(BIN): 43FPS |
|
|
Any size ROI |
|
|
Pixels Size |
1.67μm×1.67μm |
|
Scan Mode |
Progressive scan |
|
Shutter Mode |
Electronic Rolling Shutter |
|
Exposure Time* |
0.070-3000 ms |
|
Image data format* |
Raw8/Raw10/Raw12 |
|
Sensitivity* |
0.31V/Lux-sec(550nm) |
|
spectral response |
380nm-650nm(with IR-filter) |
|
SNR |
34dB |
|
Dynamic Range |
65.2dB |
|
Definition |
1500 line |
|
Exposure control |
Manual/auto/area exposure |
|
White Balance |
Manual White Balance/one time White Balance/area White Balance |
|
Hardware upgrade |
Remote upgrade |
|
Camera ID |
Support customer ID input |
|
Picture format |
RAW、BMP、JPG、PNG |
|
Programming control |
Camera working speed, picture size, format, brightness, exposure time, contrast, RGB plus, arc strobe, GAMMA, RGB plus, saturation, black balance, sharpness |
|
System |
Windows XP(32); Win7(32/64) 、Win8(32/64) |
|
Software interface |
TWAIN，Direct Show |
|
Data interface |
USB2.0 480Mb/s |
|
Camera hint |
LED light on, flash for working |
|
Capacity |
Working 1.5W, stand by about 0.5W |
|
Power supply |
USB5V |
|
Working Temperature |
0~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Working humidity |
10%-90%RH |
|
Storage humidity |
10%-60%RH |
|
Lens interface |
C |
|
Model |
MIC-C500 USB2.0 |
|
Sensor Type |
1/2.5" color CMOS |
|
Pixel |
2592×1944（5M） |
|
Resolution and frame rate |
2592×1944：9FPS |
|
2048×1536（ROI）14 FPS |
|
|
1920×1080（ROI）21.3 FPS |
|
|
1280×960（SUM）35 FPS |
|
|
1280×960（BIN）35 FPS |
|
|
640×480（SUM）55 FPS |
|
|
640×480（BIN）55 FPS |
|
|
Any size ROI |
|
|
Pixels Size |
2.2μm×2.2μm |
|
Scan Mode |
Progressive scan |
|
Shutter Mode |
Electronic Rolling Shutter |
|
Exposure Time |
0.036~300ms |
|
Image data format |
8bit/10bit/12bit |
|
Sensitivity |
1.76V/Lux-sec(550nm) |
|
SNR |
38.5dB |
|
Dynamic Range |
67.7dB |
|
Definition |
1100-1200 line |
|
Exposure control |
Manual/auto/area exposure |
|
White Balance |
Manual White Balance/ one time White Balance/area White Balance |
|
Hardware upgrade |
Remote upgrade |
|
Camera ID |
Support customer ID input |
|
Picture format |
RAW、BMP、JPG、PNG |
|
Programming control |
Camera working speed, picture size, format, brightness, exposure time, contrast, RGB plus, arc strobe, GAMMA, RGB plus, saturation, black balance, sharpness |
|
System |
Windows XP(32); Win7(32/64) ; Win8(32/64) |
|
Software interface |
TWAIN，Direct Show |
|
Data interface |
USB2.0 480Mb/s |
|
Camera hint |
LED light on, flash for working |
|
Capacity |
Less than 1.5W when working, stand by about0.5W |
|
Power supply |
USB5V |
|
Working Temperature |
0~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Working humidity |
10%-90%RH |
|
Storage humidity |
10%-60%RH |
|
Lens interface |
C/CS |
|
Model |
MIC-C300 USB2.0 |
|
Sensor Type |
1/2" color CMOS |
|
Pixel |
2048×1536(3M) |
|
Resolution and frame rate |
2048×1536:12FPS |
|
1920×1080(ROI):18FPS |
|
|
1024×768(ROI):40.4FPS |
|
|
1024×768(BIN):33FPS |
|
|
640×480(ROI):83FPS |
|
|
Any size ROI |
|
|
Pixels Size |
3.2μm×3.2μm |
|
Scan Mode |
Progressive scan |
|
Shutter Mode |
Electronic Rolling Shutter |
|
Exposure Time |
0.02~300ms |
|
Image data format |
8bit/10bit |
|
Sensitivity |
>1.0V/Lux-sec(550nm) |
|
SNR |
43 dB |
|
Dynamic Range |
61 dB |
|
Definition |
850 line |
|
Exposure control |
Manual/auto/area exposure |
|
White Balance |
Manual White Balance/one time White Balance/ area White Balance |
|
Hardware upgrade |
Remote upgrade |
|
Camera ID |
Support customer ID input |
|
Picture format |
RAW、BMP、JPG、PNG |
|
Programming control |
Camera working speed, picture size, format, brightness, exposure time, contrast, RGB plus, arc strobe, GAMMA, RGB plus, saturation, black balance, sharpness |
|
System |
Windows XP(32); Win7(32/64) ; Win8(32/64) |
|
Software interface |
TWAIN, Direct Show |
|
Data interface |
USB2.0 480Mb/s |
|
Camera hint |
LED light on, flash for working |
|
Capacity |
Less than 1.5W |
|
Power supply |
USB5V |
|
Working Temperature |
0~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Working humidity |
10%-90%RH |
|
Storage humidity |
10%-60%RH |
|
Lens interface |
C |
|
Size |
80×87.7×38mm |
|
Weight |
About350g |
|
Model |
MIC-C130 black white USB2.0 |
|
Sensor type |
1/2" black and white CMOS |
|
Pixel |
1280×1024(1.3M) |
|
Resolution and frame rate |
1280×1024:30FPS |
|
1024×768(ROI):38.7FPS |
|
|
640×480(ROI):55FPS |
|
|
320×256(ROI):93FPS |
|
|
Any size ROI |
|
|
Pixels Size |
5.2μm×5.2μm |
|
Scan Mode |
Progressive scan |
|
Shutter Mode |
Electronic Rolling Shutter |
|
Exposure Time |
0.01~300ms |
|
Image data format |
8bit/10bit |
|
Sensitivity |
2.1V/Lux-sec |
|
SNR |
45 dB |
|
Dynamic Range |
68.2dB |
|
Definition |
800 line |
|
Exposure control |
Manual/auto/area exposure |
|
White Balance |
Manual White Balance/one time White Balance/area White Balance |
|
Hardware upgrade |
Remote upgrade |
|
Camera ID |
Support customer ID input |
|
Picture format |
RAW、BMP、JPG、PNG |
|
Programming control |
Picture size, format,, exposure time, contrast, RGB plus, arc strobe, GAMMA, RGB plus, saturation, black balance, sharpness |
|
System |
Windows XP(32); Win7(32/64) ; Win8(32/64) |
|
Software interface |
TWAIN，Direct Show |
|
Data interface |
USB2.0 480Mb/s |
|
Camera hint |
LED light on, flash for working |
|
Capacity |
Less than 1.5W when working, stand by about 0.9W |
|
Power supply |
USB5V |
|
Working Temperature |
0~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Working humidity |
10%-90%RH |
|
Storage humidity |
10%-60%RH |
|
Lens interface |
C |
|
Size |
80×87.7×38mm |
|
Weight |
About350g |
