New microscope system, MIC-S1 series of biological microscopes, it has excellent optical properties and multiple functions of the observation.

Features:

1. The most advanced optical design, infinity optical system, and the optical imaging quality.

1. 2. Semi-Apochromatic infinity flat-field lens

1. 3. Large and flat field of view, field of view diameter ф26

Configuration:

Objective Lens：Apochromatic semi-infinite flat-field lens Plan SApo 4×、10×、20×、40×、100×（Oil）

Eyepiece：Large field of view of the high-eye point of flat-field eyepiece 10×（Φ26）、15×（Φ17）（Optional）

Optical system：UIS Infinity optical system

Observation tube：Φ26 field of view，trinocular tubes，Angle of 30°

1/2″CCD appropriate lens and standard C interface（MIC-S1）

Digital system：built-in 3,000,000 pixels CMOS，USB interface（MIC-S1）

Lighting system：Transmission Kohler illumination system, aplanatic condenser, 12V30W halogen

Digital voltage meter, Built-in filter (yellow, green, blue, neutral)

Focus System: Coarse micro coaxial, 40 mm stroke

Loading table: XY movement range 55 × 80 mm, right hand (or left) hand wheel coaxial low.

Converters: tin converter

Power system: 90 ~ 260V/50 ~ 60Hz

Optional:

 1.12 V50W halogen, 12V100W halogen             4.fluorescence device

 2. Phase contrast device                                 5. Polarizing device

 3.dark field device                                          6. Professional digital camera

Advanced Transmission & Reflection Microscope MIC-S12 Series

Advanced bright field transmission & reflection microscope MIC-S12B

Advanced bright dark field transmission & reflection microscope MIC-S12BD

Features:

Kohler dual optical path lighting, to be bright and uniform lighting.

Loading table contents using high-abrasion resistance of materials that can be subject to frequent replacement of samples and specimens mobile.

XY Mobile adjustment handwheel can swap around. Contents loading table trip 40mm, XY Mobile area 55 × 80mm.

Microscope equipped with a neutral color correction filter and filter. Just next to the base with your fingers pull the rod, you can quickly and easily filter insertion or withdrawal of the optical path.

Configuration

  Optical System: UIS infinity optical system

 Objective: semi-flat-field apochromatic lens infinity Plan SApo 4 ×, 10 ×, 20 ×, 40 ×, 100 × (Oil) (MIC-S12B Type)

 [Long working distance objective lens shading field metallographic

 4 × (29.4 mm), 10 × (16 mm), 20 × (10.5 mm),  40 × (5.4 mm), (MIC-S12BD-type)]

 Eyepiece: large field of view eyepiece 10 × (Φ26), 15 × (Φ17) (buy)

 Observation tube: Φ26 field, trinocular tube with an inclination of 30 ° 1 / 2 "CCD optical appropriate.

Standard C interface.

Dual optical path lighting system: lighting system transmission Kohler, aplanatic condenser, 12V30W halogen

Digital voltage meter, Built-in filter (yellow, green, blue, neutral)

Kohler reflective lighting system [(with polarizing device) (MIC-S12BD-type)], 12V50W halogen

Built-in filter (yellow, green, blue, neutral)

Focus System: Coarse micro coaxial, travel 40 mm

Contents loading table: XY movement range 55 × 80 mm, right hand (or left) hand wheel coaxial low.

Converters: tin converter

Power System: 90 ~ 260V/50 ~ 60Hz

Matching

1. 12 V100W halogen

2. Professional digital camera interface

3, flat-field far more than an unlimited long distance work metallographic objective

   20 × (10.5 mm), 40 × (5.4 mm), 50 × (9.09 mm)

  60 × (7.01 mm), 100 × (6.38 mm) (MIC-S12B Type)

  [Flat-field far more than an unlimited long distance work metallographic objective

  50 × (9.09 mm) 60 × (7.01 mm), 100 × (6.38 mm) (MIC-S12BD-type)]
