Digital Comparison Microscope MIC-W12B
By optical zoom, comparison microscope is used for macro of micro comparison of two or more objects in cutting or overlapping view field through one group of eyepieces observing left and right objective view fields. As clear imaging, high resolution, so you can identify the small differences.
Features and Functions:
Comparison microscope MIC-W12B is a newly develop product learn from advanced features of German and Swiss instruments improved on comparison microscope MIC-W8. The main features of which are:
|
1. Zooming range wide, objective lens is continuously changeable from 0.7X~4.5X; 0.4X and 2X auxiliary objective lenses in addition. Thus, the smallest total magnification is 3.6X, while the biggest is 234X when eye viewing. |
|
2. It has two sets of embedded digital CCD camera system, which is electronically controlled: Embedded digital colored video recording system—synchronized with eye viewing. Embedded digital black and white video recording system— is for infrared comparison use. Infrared color filters passing wavelengths are: 700, 800, 850, 900, 950 five files, electronically controlled. Optical analyzing comparison images, with 3 mega pixels condenser, directly shift optical signals into digital signals, input into computer or AV/VGA/DAI display. |
|
3. Using wide angle large view field binocular observing system to fatigue observers’ eye fatigue. In witch: 10X/φ22mm, 20X/φ12 mm. |
|
4. Photographing system can be equipped with all models of digital cameras. |
|
5. Simultaneously equipped with 24V150W optic fiber cold light source and adjustable white LED light source, tricolors LED light source; light source of which brightness high, cooling effect good, application range wide, and easy to use. |
|
6. Left and right two objective stages can left and right linkage scan. |
|
7. With magnification correcting plates, magnification of left and right system is extremely consistent. |
|
8. Can realize left and right single view field, cutting view filed, overlapping view field observation. |
|
9. Left and right working stages can achieve left and right, front and behind electronic transmission, electronic linkage; column is electronically lifting; easy to use. |
|
10. View field cutting ridge width is adjustable in consistency. |
|
This product is an ideal instrument for public security, attorney, courts on documentation retrieval, trace inspection and school teaching (comparison and identification on bullets, tool marks, finger prints, seals, texts, coins and so on), also applied to fields and sectors such as banks, archeology, electronics, biology, agriculture, etc. which need to make comparison and identification on objects. |
Accessories:
|
Binocular head. |
LED light source |
10X eyepieces |
|
20X eyepieces |
Photographing tube |
Optic fiber cold light source |
|
lenses |
Low magnification objective |
Magnification correcting plates |
|
Co-axial |
Bullet holder |
2X additional objective lenses |
|
Monitor |
|
|
