0.35M pixel CMOS camera
|
HARDWARE CONFIGURATION |
||
|
Image Pickup Device |
APTINA MT9V011 CMOS COLOR |
|
|
Scan Mode |
Progressive |
|
|
Max. Resolution |
640 x 480 (Approx. 350,000 Pixels) |
|
|
Sensor Size (Diagonal) |
1/4“ (3.58mm(H) x2.69mm(V), Diagonal4.48mm) |
|
|
Pixel Size |
5.6µm x 5.6µm |
|
|
G Sensitivity |
1.9v/lux-sec(550nm) |
|
|
Dynamic Range |
60dB |
|
|
A/D Converter |
10-bit Parallel, 8-bit R.G.B to PC |
|
|
SN Ratio |
45dB |
|
|
Spectral Range |
380-650nm (with IR-filter) |
|
|
Video Format & Frame Rate |
30fps @640 x 480, 80fps @320 x 240 (Multiple Speed Level) |
|
|
Binning |
1 x 1, 2 x 2 |
|
|
Exposure |
0.11~192.46ms, ROI Auto & Manual |
|
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
|
Peak Quantum Efficiency |
35% |
|
|
Readout Noise |
N/A |
|
|
Extinction Ratio |
N/A |
|
|
Smear |
N/A |
|
|
Capture/Control API |
DirectShow , Twain |
|
|
Recording System |
Still Picture and Movie |
|
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
|
OPERATING ENVIRONMENT |
||
|
Operating Temperature |
-10℃~50℃ |
|
|
Storage Temperature |
-20℃~60℃ |
|
|
Operating Humidity |
30~80%RH |
|
|
Storage Humidity |
10~60%RH |
|
|
Power Supply |
DC 5V over PC USB port |
|
|
SOFTWARE ENVIRONMENT |
||
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
|
Memory:2GB or more |
||
|
USB port:USB2.0 High-speed Port |
||
|
Display:17" or larger |
||
|
CD-ROM |
||
1.3 M pixel CMOS camera
|
HARDWARE CONFIGURATION |
||
|
Image Pickup Device |
APTINA MT9M111 CMOSCOLOR |
|
|
Scan Mode |
Progressive |
|
|
Max. Resolution |
1280 x 1024 (Approx. 1,300,000 Pixels) |
|
|
Sensor Size (Diagonal) |
1/3“ (4.60mm(H) x3.70mm(V), Diagonal5.9mm) |
|
|
Pixel Size |
3.6μm x 3.6μm |
|
|
G Sensitivity |
1.0v/lux-sec(550nm) |
|
|
Dynamic Range |
71dB |
|
|
A/D Converter |
10-bit, 8-Bit R.G.B to PC |
|
|
SN Ratio |
44dB |
|
|
Spectral Range |
380-650nm (with IR-filter) |
|
|
Video Format & Frame Rate |
15fps @1280 x 1024, 26fps @640 x 512, 50fps @320 x 256 |
|
|
Binning |
1 x 1, 2 x 2, 4 x 4 |
|
|
Exposure |
0.140~2000ms,ROI Auto & Manual |
|
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
|
Peak Quantum Efficiency |
35% |
|
|
Readout Noise |
N/A |
|
|
Extinction Ratio |
N/A |
|
|
Smear |
N/A |
|
|
Capture/Control API |
DirectShow , Twain |
|
|
Recording System |
Still Picture and Movie |
|
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
|
OPERATING ENVIRONMENT: |
||
|
Operating Temperature |
-10℃~50℃ |
|
|
Storage Temperature |
-20℃~60℃ |
|
|
Operating Humidity |
30~80%RH |
|
|
Storage Humidity |
10~60%RH |
|
|
Power Supply |
DC 5V over PC USB port |
|
|
SOFTWARE ENVIRONMENT |
||
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
|
Memory:2GB or more |
||
|
USB port:USB2.0 High-speed Port |
||
|
Display:17" or larger |
||
|
CD-ROM |
||
2M pixel CMOS camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
APTINA CMOSCOLOR |
|
Scan Mode |
Progressive |
|
Max. Resolution |
1600 x 1200 (Approx. 2,000,000 Pixels) |
|
Sensor Size (Diagonal) |
1/3“ (5.12mm(H) x3.84mm(V), Diagonal6.40mm) |
|
Pixel Size |
3.2μm x 3.2μm |
|
G Sensitivity |
1.0v/lux-sec(550nm) |
|
Dynamic Range |
71dB |
|
A/D Converter |
12-bit, 8-Bit R.G.B to PC |
|
SN Ratio |
42.3dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
16fps @1600 x 1200, 50fps @800 x 600 |
|
Binning |
1 x 1, 2 x 2 |
|
Exposure |
0.128~2000ms, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
3 M pixel CMOS camera
|
HARDWARE CONFIGURATION: |
|
|
Image Pickup Device |
APTINA MT9T001 CMOSCOLOR |
|
Scan Mode |
Progressive |
|
Max. Resolution |
2048 x 1536 (Approx.3,200,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2“ (6.55mm(H) x4.92mm(V), Diagonal8.19mm) |
|
Pixel Size |
3.2μm x 3.2μm |
|
G Sensitivity |
1.0v/lux-sec(550nm) |
|
Dynamic Range |
61dB |
|
A/D Converter |
10-bit, 8-Bit R.G.B to PC |
|
SN Ratio |
43dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
8fps @2048 x 1536, 22fps @1024 x 768, 43fps @680 x 510 |
|
Binning |
1 x 1, 2 x 2, 3 x 3 |
|
Exposure |
0.128~2000ms, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT: |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
5M pixel CMOS camera
|
HARDWARE CONFIGURATION: |
|
|
Image Pickup Device |
APTINA MT9P001 CMOSCOLOR |
|
Scan Mode |
Progressive |
|
Max. Resolution |
2592 x 1944 (Approx.5,040,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2.5“ (5.70mm(H) x4.28mm(V), Diagonal7.13mm) |
|
Pixel Size |
2.2μm x 2.2μm |
|
G Sensitivity |
0.53v/lux-sec(550nm) |
|
Dynamic Range |
66.5dB |
|
A/D Converter |
10-bit, 8-Bit R.G.B to PC |
|
SN Ratio |
40.5dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
5fps @2592 x 1944, 18fps @1280 x 960, 60fps @640 x 480 |
|
Binning |
1 x 1, 2 x 2, 4 x 4 |
|
Exposure |
0.21~2000ms,ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT: |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
8Mpixel CMOS camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
APTINA CMOSCOLOR |
|
Scan Mode |
Progressive |
|
Max. Resolution |
3264 x 2448 (Approx.8,000,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2.5“ (5.451mm(H) x4.088mm(V), Diagonal6.813mm) |
|
Pixel Size |
1.67μm x 1.67μm |
|
G Sensitivity |
0.31v/lux-sec(550nm) |
|
Dynamic Range |
65.2dB |
|
A/D Converter |
10-bit, 8-Bit R.G.B to PC |
|
SN Ratio |
34dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
1.9fps @3264 x 2448, 8fps @1600 x 1200, 27fps @800x600 |
|
Binning |
1 x 1, 2 x 2, 4 x 4 |
|
Exposure |
0.38~2000ms, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT: |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
9M pixel CMOS camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
APTINA CMOSCOLOR |
|
Scan Mode |
Progressive |
|
Max. Resolution |
3488 x 2616 (Approx.9,000,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2.4“ (5.825mm(H) x4.369mm(V), Diagonal7.281mm) |
|
Pixel Size |
1.67μm x 1.67μm |
|
G Sensitivity |
0.33v/lux-sec(550nm) |
|
Dynamic Range |
65.2dB |
|
A/D Converter |
10-bit, 8-Bit R.G.B to PC |
|
SN Ratio |
34dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
1.9fps @3488 x 2616, 8fps @1744 x 1308, 27fps @872 x 654 |
|
Binning |
1 x 1, 2 x 2, 4 x 4 |
|
Exposure |
0.38~2000ms, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
10M pixel CMOS camera
|
HARDWARE CONFIGURATION: |
|
|
Image Pickup Device |
APTINA MT9J001 CMOSCOLOR |
|
Scan Mode |
Progressive |
|
Max. Resolution |
3584 x 2748 (Approx. 10,000,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2.3“ (6.119mm(H) x4.589mm(V), Diagonal7.649mm) |
|
Pixel Size |
1.67μm x 1.67μm |
|
G Sensitivity |
0.31v/lux-sec(550nm) |
|
Dynamic Range |
65.3dB |
|
A/D Converter |
10-bit, 8-Bit R.G.B to PC |
|
SN Ratio |
34dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
1.9fps @3584 x 2748, 8fps @1792 x 1374, 27fps @896 x 684 |
|
Binning |
1 x 1, 2 x 2, 4 x 4 |
|
Exposure |
0.38~2000ms, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
14M pixel CMOS camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
APTINA MT9F001 CMOSCOLOR |
|
Scan Mode |
Progressive |
|
Max. Resolution |
4096 x 3288 (Approx. 14,000,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2.3“ (6.138mm(H) x4.603mm(V), Diagonal7.672mm) |
|
Pixel Size |
1.4μm x 1.4μm |
|
G Sensitivity |
0.724v/lux-sec(550nm) |
|
Dynamic Range |
65.3dB |
|
A/D Converter |
10-bit, 8-Bit R.G.B to PC |
|
SN Ratio |
35.5dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
1.8fps @4096 x 3288,10fps @2048 x 1644,27fps @1024 x 822 |
|
Binning |
1 x 1, 2 x 2, 4 x 4 |
|
Exposure |
0.4~2000ms, ROI Auto & Manual |
|
White balance |
One Push ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMColor Engine |
|
Peak Quantum Efficiency |
35% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
Nature, Optional: PELTIER (Semiconductor Cooling Module) |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
