MIC-T8 serials zoom stereo microscope, providing high-quality, durable and reliable optical system and operating mechanism. New design show the best resolution and true color images, to meet the modern biomedical research, modern electronics industry online testing and other technology industries such as high-precision requirements
Technical Data Sheet
M means total magnification, V means filed of view(mm), W means working distance(mm)
|
auxiliary lens |
W |
eyepiece |
|||||
|
10x22mm |
15x16mm |
20x12.5mm |
|||||
|
M |
V |
M |
V |
M |
V |
||
|
None |
115 |
8x ~ 50x |
φ27.5 ~ φ4.4 |
12x ~ 75x |
φ20 ~ φ3.2 |
16x ~ 100x |
φ15.6 ~ φ2.5 |
|
AL0.5x |
211 |
4x ~ 25x |
φ55.0 ~ φ8.8 |
6x ~ 37.5x |
φ40 ~ φ6.4 |
8x ~ 50x |
φ31.2 ~ φ5.0 |
|
AL2x |
43.5 |
16x ~ 100x |
φ13.8 ~ φ2.2 |
24x ~ 150x |
φ10 ~ φ1.6 |
32x ~ 200x |
φ7.8 ~ φ1.3 |
|
Head |
binocular stereoscope body , inclination 45 ° |
|
trinocular stereo microscope body , inclination 45 ° |
|
|
Diopter adjustable eyepiece: Wide Field Eyepiece EW10 × / / Φ22 WF15 × / Φ16 WF20 × / Φ12 WF30 × |
|
|
zoom lens |
0.8 × -5 × |
|
Zoom ratio |
6.3:1 |
|
Working Distance115mm |
|
|
IPD 52-75mm |
|
|
Auxiliary lens 0.5 × 0.7 × 2 × |
|
|
Stage into the circular plate125mmdiameter transparent glass plate white plate |
|
|
lighting system: no light OR reflected light 100V-240V/LED OR transmitted light illumination 100V-240V/LED |
|
|
photography accessories camera accessories |
|
|
|
A3 industrial binding Focus Frame (industry-specific) |
|
base |
B2 Column transmission base, the upper and lower light source is a halogen lamp 12V15W (adjustable brightness), (7W fluorescent optional) |
|
other external sources |
ring light / LED light / fiber optic lighting |
