Model

LY6001

Eyepiece

Wide field  WF10X(µ22mm)

Objective

Infinity plan achromatic objectives

PL 4X/0.10  (Work distance)：19.8 mm

PL 10X/0.25 (Work distance)：5.0 mm

PLF L40X/0.85£¨spring£© (Work distance)：0.42 mm (No magnification spherochromatic aberration )

PL 100X/1.25(Spring, oil) (Work distance)：0.36mm

Eyepieces tube

Trinocular, Inclination of 30˚.

Epi-fluorescent illumination system

3W high brightness LED. Enable selecting monochromatic or bichromatic LED for light source, every monochromatic LED wave band: Green (520nm~530nm) Blue( 460nm~470nm)

Fluorescence filters: B(Blue) and G(Green).

Focus system

Coaxial coarse/fine focus system, with tension adjustable and limit stopper, minimum division of fine focusing: 2μm.

Nosepiece

Quadruple(Backward ball bearing inner locating)

Stage

Double layer mechanical (Size:210mmX140mm,movingrange:75mmX50mm)

Transmitted illumination

system

Abbe condenser  NA.1.25  Rack & pinion adjustable

Blue filter and Ground glass

Collector for LED illumination and integrated field diaphragm

3W high brightness white LED, brightness adjustable.

Optional accessories

Sort/Technique parameter

NO.

Eyepiece

Dividing eyepiece(field number:µ22mm)    0.10mm/Div

1122010

Objective

Infinity plan achromatic objective PL 60X/0.80(Work distance)：0.46 mm

2060160

Infinity plan achromatic fluorescent objective

PL FL10X/0.35(Work distance)：2.37 mm

2610110

Nosepiece

Quintuple(Backward ball bearing inner locating)

032002

Filter

Green filter

115002

Yellow filter

115003

LED

Violet(390nm~400nm)

/

Ultraviolet(360nm~370nm)

/

Fluorescent filters

V(Violet)

/

UV(Ultraviolet)

/

CCD adapter

0.4X

810001

0.5X

810004

1X

810002

0.5X with dividing0.1mm/Div

810003

Camera

DV-1  Video output(380/520 TV line) USB output (0.42 Mpixel)

800001

DV-2  With USB output (1.3M,2.0M,3.0Mpixel)

800003

DV-3  With video output(380/520 TV line)

800005

Digital camera adapter

CANON(EF)  NIKON( F)

820001
