Standard configurations
|
Objective zoom range |
1X-2X 1X-3X 2X-4X |
|
Eyepice |
SWF 10X/23mm |
|
Working distance |
120mm |
|
Interpupillary distance adjustment range |
55mm-75mm |
|
Binocular head |
inclination of 45。 |
|
Diopter adjustment |
±5 diopter |
|
Optical Body Rotation 360。 |
360 |
Technical data
|
Auxiliary |
Eyepiece |
Magnification |
Visual field |
Working distance(mm) |
|
1X,2X |
10X |
10X，20X |
23，11.5 |
120 |
|
15X |
15X，30X |
16，8 |
||
|
20X |
20X，40X |
13，6.5 |
||
|
25X |
25X，50X |
12，6 |
||
|
1X,3X |
10X |
10X，30X |
23，7.6 |
120 |
|
15X |
15X，45X |
16，5.3 |
||
|
20X |
20X，60X |
13，4.3 |
||
|
25X |
25X，75X |
12，4 |
||
|
2X,4X |
10X |
20X，40X |
11.5，5.7 |
120 |
|
15X |
30.X，60X |
8，4 |
||
|
20X |
40X，80X |
6.5，3.3 |
||
|
25X |
50X，100X |
6，3 |
||
|
1X,4X |
10X |
10X，40X |
23，5.7 |
120 |
|
15X |
15X，60X |
16，4 |
||
|
20X |
20X，80X |
13，3.3 |
||
|
25X |
25X，100X |
12，3 |
