Items

Spec.and Parameter

H6202

H6203

H6302

H6303

H6500

Order No.

Eyepiece

10X-18

●●

●●

●●

●●

●●

EP10a

Plan

Achromatic

Objectives

S-Plan 10/0.25

●

●

B-OSPr10

S-Plan 25/0.40

●

●

B-OSPr25

S-Plan 40/0.65

●

●

B-OSPr40a

S-Plan 100/1.25(Oil)

●

●

B-OSPor100

Plan 10/0.25

●

●

●

B-OPr10

Plan 25/0.40

●

●

B-OPr25

Plan 40/0.65

●

●

B-OPr40

Plan 100/1.25(Oil)

●

●

B-OPor100

Eyepiece

Heads

Binocular Head

(30°Inclined, Seidentopf)

●

●

TBR06

Trinocular head

(30°Inclined, Seidentopf)

●

●

●

TTR02

Main Body

Worm and Gear

Focusing Mechanism、

Quadplex Nosepiece

●

●

●

●

●

A13

Mechanical Stage

Moving Range: 76x50mm

Size: 160x135mm

●

●

●

●

●

S30

Condenser

N.A. 1.25

●

●

C05

N.A. 1.25

●

●

●

C23

Condenser

Focusing

Team

Rack and Pinion

Focusing Mechanism

●

●

●

●

●

CA03a

Base

Knob Switch、6V20W Halogen Tungsten Lamp

●

●

●

●

●

B30

Fluorescence

Objectives

25/0.65

●

B-OFr25

40/1(Glycerin)

●

B-OFor40

100/1.25(Glycerin)

●

B-OFor100

Epi-fluorescence Main Body (B、G)

●

FD07

100W Mercury Lamp House

●

LH08

Power Supply Case of 100W

Mercury Lamp

●

LS14

Glycerin

●

Immersion Oil

●

●

●

●

Filter

Ø 32 (Blue)

●

●

●

●

CU02-1

Items

Spec.And.Parameter

Order No.

Eyepieces

10X-20

EW10

10X-18(Pointer)

Erg10

16X-10

EP16a

16X-14

EW16

Plan Achromatic Objectives

S-Plan 4/0.10

B-OSPr4

Plan 4/0.10

B-OPr4

Phase Contrast Attachment

 Plan Positive Ph. Objectives

S-Plan ph10/0.25

B-OSPpr10

S-Plan ph40/0.65

B-OSPpr40a

S-Plan ph100/1.25(Oil)

B-OSPopr100

Plan ph10/0.25

B-OPpr10

Plan ph40/0.65

B-OPpr40

Plan ph100/1.25(Oil)

B-Opopr100

Plan Negative Ph. Objectives

S-Plan ph10/0.25

B-OSPnr10

S-Plan ph40/0.65

B-OSPnr40a

S-Plan ph100/1.25(Oil)

B-OSPonr100

Plan ph10/0.25

B-OPnr10

Plan ph40/0.65

B-OPnr40

Plan ph100/1.25(Oil)

B-OPonr100

Ph Condenser Only for S-Plan Ph. Objective

C06a

Ph Condenser Only for Plan Ph Objective

C06

Centering Eyepiece 8X

EC8

Main Body

Worm and gear Focusing Mechanism、Quintuple Nosepiece

A13a

Eyepiece

Heads

Binocular Head (45°Inclined; Seidentopf)

TBR07

Trinocular Head (45°Inclined; Seidentopf)

TTR03

Binocular Head (30°Inclined, Sliding)

TB07

Trinocular Head (30°Inclined, Sliding)

TT06

Binocular Head (45°Inclined, Sliding)

TB08

Trinocular Head (45°Inclined, Sliding)

TT07

Dark Field Attachment

Dark Field Condenser (N.A. 0.83-0.91)

C07

Polarizing Attachment

Polarizer Slide

PO01

Analyzer Slide

PA01

Photo Attachment

10X Reticule Eyepiece

EPr10b

2.5X Photo Eyepiece

EPHn2.5

4X Photo Eyepiece

EPHn4

6.3X Photo Eyepiece

EPHn6.3

135 Photo Device (With 4x Photo Eyepiece)

MP03

TV and Video Attachment

C-mount Adaptor、Color or Black and White Monitor、CCD Camera

TV02

Epi-fluorescence Attachment

Epi-fluorescence Main Body (B.G.V.UV)

FD08

Power Supply Case of 200W Mercury Lamp

31X.3

200W Mercury Lamp House

31X.2.2

Side Viewing Attachment

Two View Field Space600mm

TB06

Epi-illumination Attachment

6V20W Halogen Tungsten Lamp (With Reflector)

H09

Filter

Ø 32 (Green、Amber)

CU02-2、3

Image Analysis and Disposal System
