Specification |
XSZ-N24 |
XSZ-N24D |
XSZ-N24DT |
|
|
Viewing Head |
Monocular Inclined at45°,360°Rotatable |
● |
|
|
|
Compensation Free Binocular Head inclined at 30°(55mm-75mm) |
|
● |
|
|
|
Compensation Free Trinocular Head inclined at 30°(55mm-75mm) |
|
|
● |
|
|
Eyepiece |
WF10×/18mm |
● |
● |
● |
|
Objective |
Achromatic 4×、10×、40×(s)、100×(s)oil |
● |
● |
● |
|
Stage |
Stage size:120mm×125mmMechanical stage Moving range:60mm×30mm |
● |
● |
● |
|
Condenser |
N.A.1.25Abbe Condenser with iris diaphragm and filter |
● |
● |
● |
|
Focusing |
Separated coarse & fine focusing adjustment |
● |
● |
● |
|
Light Source |
Halogen bulb 6V/20W,AC 220V/110V Adjustable light source |
● |
● |
● |
|
Optional Accessory |
Eyepiece:WF16×、WF20×、P16× |
|||
|
Objective:20×、60×(s) |
||||
|
Semi-plan or Plan-achromatic objectives |
||||
|
Reflective Mirror, Demonstration(Teaching)Head |
||||
|
CCD Adapter |
||||
|
Compensation Free Binocular & Trinocular Head(48mm-75mm) |
||||
|
LED illumination |
||||
|
Fluorescent lamp 220V/5W or 110V/5W |
||||
