High efficiency, flexibility and stability are the characters of this series microscope. It is specially developed for various applied scopes. It is widely used, from daily work to scientific research, in Laboratory, Hospitals and Colleges. Because of higher capability with lower price and humanized configuration design, It also becomes the first choice of individual, Schools, and Scientific research organization.
Features:
1. Wide-field
Eyepiece, high light illumination and superior optical parts make the image
clear, sharp and bright.
2. Backward nosepiece with superior objectives makes the best viewing effect
and more space for the operator.
3. Wide mechanical stage with 2-Microslide specimen clamp provides more convenience
for the observer.
4. High precision focusing adjustment system and humanized configuration design
provide operator more comfortable.
5. Frontal undrawing type Light collector framework, makes the user change the
bulb more quickly and easily.
|
Specification |
XSZ-N6 |
XSZ- N6T |
XSZ- N6A |
XSZ- N6AT |
|
|
Viewing head |
Sliding Binocular Head.Inclined at 45 ° (52mm-74mm) |
● |
|
|
|
|
Compensation Free Binocular Head . Inclined at 30 ° (55mm-75mm) |
|
|
● |
|
|
|
Sliding Free Trinocular Head .Inclined at 45 ° (52mm-74mm) |
|
● |
|
|
|
|
Compensation Free Trinocular Head . Inclinedat30 ° (55mm-75mm) |
|
|
|
● |
|
|
Eyepiece |
WF10 × |
● |
● |
● |
● |
|
Objective |
Achromatic objective: objective: 4X,10X,40X(S),100X(S)Oil |
● |
● |
● |
● |
|
Stage |
Double layers mechanical stage |
● |
● |
● |
● |
|
Stage size:180mmX150mm |
● |
● |
● |
● |
|
|
Moving range :75mmX50mm |
● |
● |
● |
● |
|
|
Condenser |
N.A.1.25Abbe condenser with iris diaphragm & filter |
● |
● |
● |
● |
|
Focusing |
Coaxial coarse&fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value0.002mm |
● |
● |
● |
● |
|
Collector |
High brightness Kohler illumination |
● |
● |
● |
● |
|
Light source |
Halogen tungsten bulb12V/20W.AC85V- 230V |
● |
● |
● |
● |
|
Adjustable brightness |
|||||
|
Optional Accessory |
Eyepieces: WF16x,WF20x,P16x |
||||
|
CMOS electronic eyepiece of 1.3 Mega pixels |
|||||
|
Plan-Objectives: 4X,10X,20X(S),40X(S),60X(S),100X(S)Oil |
|||||
|
Semi-plan objectives: 4X,10X,20X(S),40X(S),60X(S),100X(S)Oil |
|||||
|
Infinity objectives: X,10X,20X(S),40X(S),60X(S),100X(S)Oil |
|||||
|
Phase Contrast Attachment |
|||||
|
photo and CCD atachment |
|||||
