Comparison Microscope MIC-W9A
By optical zoom, comparison microscope is used for macro of micro comparison of two or more objects in cutting or overlapping view field through one group of eyepieces observing left and right objective view fields. As clear imaging, high resolution, so you can identify the small differences
Comparison microscope MIC-W9Ais a new generation of product developed by our company by having accumulated many years of experiences, fully absorbed essences at home and abroad, this product successfully solved the technical problems of comparing ridge width and consistency adjustable (this technology is included in the national technology security projects), so the main technical performance of the comparison microscope reached the international advanced level.
MIC-W9Ais an upgraded product improved on MIC-W9 model, which not only retains excellent technical performances of MIC-W9, but also increases its image quality and magnification, enlarges 10X and 20X eyepieces view field diameters, added 6.3X eyepiece and 2X additional objective lens, electronic lifting linkage working stages, and so on, and keeps original illumination ways and a variety of accessories, shape, structure more beautiful, reasonable, reliable, and makes the instrument fully plays its functions of comparison and identification.
This product is an ideal instrument for public security, inspection, court on document retrieval, marks checking and school teaching (used for bullets, tool marks, fingerprints, seals, texts, coins comparison and identification), but also for industries and sectors such as banks, archaeology, electronics, biology, agriculture which need to identify on objects to use.
Binocular head horizontal adjusting device is a main feature of the instrument, and the leading top level in domestic comparison microscope fields, which adjust binocular head height to fit observers’ position according to observers’ body height, when you flip till some position, it can automatically stop moving equilibrium.
Accessories:
|
Photo block |
CCD camera |
Cold light source universal bracket |
|
Cold light source |
Tilt working stage |
Working stage |
|
Tightening screw |
Binocular head |
Binocular head horizontal adjusting device |
|
Cold light source lens |
LED light adjusting knob |
|
Technical Parameters:
|
Optical magnification range: 1.5X~200X |
|
Eyepieces: 6.3X/φ28 10X/φ22 20X/φ12 (6.3X and 20X eyepieces are for optional) |
|
Objective lens: 0.8X, 1.3X, 2X, 3.2X, 5X (0.3X, 2X additional objective) |
|
Bridge body open file size:325mm |
|
Binocular dip adjusting range: 0°~30° |
|
Height of visual center of the pupil to the table surface:410mm |
|
IPD adjusting range: 60~75mm |
|
Working distance:100mm |
|
Objective stage dimension: 100X100mmmoving range: X50mmY50mmZ55mm |
|
Horizontal linkage (manual) range:45mm |
|
Up and down linkage (electronic) lifting range:65mm |
|
Objective view field observing range: Φ1.2~Φ116mm(includes additional eyepieces and objective lens) |
|
Power supply has two types: 24V150W optic fiber cold light source, with optic lens, brightness and light spots adjustable, and 4.5V~7.5V/5W LED high power multi-waves illumination light source |
|
Power supply: 220V AC input, 24V and 4.5V~7.5V DC output, accords with international safety standard |
