Item

Specifications

MIC-T3M

MIC-T3B

MIC-T3T

Viewing head

Monocular head,30Oinclined,360Orotating

●

○

○

Binocular head of slide type. Interpupillary distance 55-75mm

○

●

○

Trinocular head of slide type. Interpupillary distance 55-75mm

○

○

●

Binocular head of articulated type. Interpupillary distance 55-75mm

○

○

○

Eyepiece

WF10X-18mm

●

●

●

WF15X-13mm

○

○

○

WF20X-11mm

○

○

○

DIN45mm

Achromatic objective

DIN achromatic objective 4X/NA0.10

●

●

●

DIN achromatic objective 10X/NA0.25

●

●

●

DIN achromatic objective 40XR/NA0.65

●

●

●

DIN achromatic objective 60XR/NA0.85

○

○

○

DIN achromatic objective 100XR(oil)/NA1.25

●

●

●

Nosepiece

Triple nosepiece with positive click stopper

○

○

○

Quadruple nosepiece with positive click stopper

●

●

●

Stage

Built-in mechanical stage 142mmX132mmwith specimen holder, controlled by coaxial knobs at low position

●

●

●

Condenser

N.A.1.25Abbe Condenser with Iris Diaphragm

●

●

●

Illuminator

Halogen bulb 6V/20W.AC85－230V

●

●

●

Option

photo adaptor

○

○

○

simple polarizing

○

○

○

Packing

Each set in a foam in a carton, than in a master carton. Master carton size: 42x32x28cm

●

●

●

Wooden case w/lock & keys

○

○

○

Aluminum-alloy Instrument Case

○

○

○
