Model

MIA-8D

MIA-8D3A

MIA-8D4A

Viewing Body

30°Incline Binocular Body，Interpupillary Adjustable Distance:55mm～75mm

●

●

30°Incline Trinocular Body，Interpupillary Adjustable Distance:55mm～75mm

●

Eyepiece

WF10×(Viewing Field Diameter:ø18mm),

WF16×(Viewing Field Diameter:ø11mm)

Adjustable Par focal Achromatic Objectives

4×/NA0.1, 10×/NA0.25, 40×(s)/NA0.65, 100×(s)/NA.1.25

●

4×/NA0.1, 10×/NA0.25，40×(s)/NA0.65, 100×(with diaphragm)/NA0.9～1.25(s, oil)

●

●

Mechanical Stage

Size:160mm×130mm, Moving Range:76mm×50mm，Venire Division:0.1mm

Nosepiece

Nosepiece of four holes revolving on ball

Condenser

Abbe Condenser：N.A.1.25，Elevating Range:15mm

●

●

●

Dark Field Condenser( Dry、Immersion )

●

●

Focusing

Coaxial Coarse/Fine Focusing Adjustment, Focusing Range:20mm，Division of Fine Focus Adjustment:0.002mm

Illumination

6V 20W Halogen Lamp With Adjustable Brightness, Free Voltage 100V-240V, Filter(blue、yellow、ground glass)
