Item |
Specifications |
||||
|
Zoom microscope body |
Zoom drive : Horizontal knob system Click stop for each zoom magnification: On-Off switching possible Zoom ratio values : 7:1 (0.8~5.6x) Zoom magnification indication: 0.8, 1, 1.25, 1.6, 2, 2.5, 3.2, 4, 5, 5.6. Objective lens mounting : Screw mounting into thread |
||||
|
Observation tube |
Trinocular tube(MIC-TR30), Binocular tube(MIC-BI30) View inclination angle : 30° Light path selection (only MIC-TR30): 2 steps (Binocular 100%, Video 80%-Binocular 20%) Interpupillary distance adjustable range : 55 to75mm Eyepiece clamping knob provided |
||||
|
Stand |
MIC-ST7 |
MIC-ILSTS7 |
MIC -ILST7 |
||
|
MIC-ST7 |
Standard large stand |
LED reflected / transmitted |
LED reflected / transmitted |
||
|
MIC-ILST7 |
Frame installation |
Mounting diameter:76mm |
|||
|
MIC-ILSTL7 |
Focusing adjustment |
Knob rotation tension adjustment Focusing storoke :120mm |
|||
|
Stage plate |
MIC-SPG MIC-SPBW |
MIC-SPG100 |
MIC-SPG MIC-SPBW |
||
|
Light source |
Transmitted illumination: LED Reflected illumination: LED Average LED life span: 10,000 hrs. Input rating: AC 100-240V, 50/60Hz, 10W |
||||
|
Objective lens |
Model MIC-ACH1x MIC-PLAPO1x MIC-ACH2x |
Working distance W/D :90.5mm W/D :81mm W/D :33.5mm |
|||
|
Eyepieces |
Eyepiece series |
||||
|
Dimensions |
290*371.1*371.6 |
||||
|
Weight |
6.86kg |
||||
