HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
SONY ICX655AQ CCD color |
|
Scan Mode |
Progressive |
|
Max. Resolution |
2448 x 2050 (Approx. 5,018,000 Pixels) |
|
Sensor Size (Diagonal) |
2/3“ (Diagonal11.016mm) |
|
Pixel Size |
3.45µm x 3.45µm |
|
Imaging Area |
9.93mm(H) x8.70mm(V) |
|
G Sensitivity |
420mV with 1/30s Accumulation |
|
Dynamic Range |
70dB |
|
A/D Converter |
12-bit Parallel, 8-bit R.G.B to PC |
|
SN Ratio |
72dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
4.3fps @2448 x 2050, 10.5fps @960 x 720 (Multiple Speed Level) |
|
Binning |
1 x 1 |
|
Long Exposure |
0.22ms~60s, ROI Auto & Manual |
|
White balance |
ROI White Balance/ Manual Temp-Tint Adjustment |
|
Color Rendering Technique |
Ultra FineTMII Color Engine |
|
Peak Quantum Efficiency |
60% |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
Native C/C++ SDK, DirectShow, Twain |
|
Recording System |
Still Picture and Movie |
|
Cooling System |
TE-Cooled CCD -20 °Cbelow ambient temperature |
|
OPERATING ENVIRONMENT: |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port for Camera External power adapter for cooling system, DC3V,5A |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows® XP /Vista/ 7 / 8 (32 & 64 bit) OS X (Mac OS X) Linux (2.6 or above) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
