Specification |
J-M6J |
J-M6JT |
J-M6JA |
J-M6JAT |
||
|
Viewing head |
Compensation Free Binocular Head. Inclined at 3 0 ° (55mm-75mm) |
● |
|
● |
|
|
|
Compensation Free Trinocular Head. Inclined at 3 0 ° (55mm-75mm) |
|
● |
|
● |
||
|
Eyepiece |
WF10 × /20mm |
● |
● |
|
|
|
|
WF10 ×/22mm |
|
|
● |
● |
||
|
WF10 ×/20mmwith reticule0.1mm |
○ |
● |
○ |
● |
||
|
Nosepiece |
Quadruple nosepiece |
● |
● |
● |
● |
|
|
Objective |
195 metallurgical objectives |
4 ×/ 0.1W.D.25mm |
● |
● |
|
|
|
10 ×/ 0.25W.D.11mm |
||||||
|
20 × /0.4W.D.9mm |
||||||
|
40 × /0.6W.D.3.8mm |
||||||
|
Infinity metallurgical objectives |
4 × /.1W.D.25mm |
|
|
● |
● |
|
|
10 ×/0.25W.D.11mm |
||||||
|
20 × /.4W.D.8mm |
||||||
|
40 × /.6W.D.3.8mm |
||||||
|
50 × /0.75W.D.1.9mm80 × /0.9W.D.0.9mm |
○ |
○ |
○ |
○ |
||
|
Stage |
Double layers mechanical stage |
● |
● |
● |
● |
|
|
Stage size:180mm×150mm |
||||||
|
Moving range:75mm×50mm |
||||||
|
Condenser |
N.A1.25 Abbe condenser with iris diaphragm&filter |
● |
● |
● |
● |
|
|
Focusing |
Coaxial coarse&fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value0.002mm |
● |
● |
● |
● |
|
|
Illumination |
Epi-Kohler illumination. With aperture iris diaphragm and field iris diaphragm Transmission light, 12V/30W.AC85V-230V Adjustable brightness |
● |
● |
● |
● |
|
|
Polarizing outfit |
Analyzer rotatable 360 ° ,polarizer &Analyzer can be slide in / out of the optical path |
● |
● |
● |
● |
|
|
Filter |
Blue, green, yellow |
● |
● |
● |
● |
|
|
Checking tool |
0.01mm micrometer |
● |
● |
● |
● |
|
|
Optional Accessory |
1.3、2.0、3.0、5.0 Mega pixels CMOS electronic eyepiece |
|||||
|
Photography attachment |
||||||
