Standard Configuration
|
Model |
XSL-105A |
XSL-105B |
|
Eyepiece |
Wide field WF10X(¦µ18mm) |
|
|
Objective |
Achromatic 4X/0.10 |
|
|
Achromatic 10X/0.25 |
||
|
Achromatic 40X/0.65(Spring) |
||
|
Achromatic 100X/1.25(Spring, oil) |
||
|
Eyepiece tube |
Binocular, Sliding(Inclination of 30˚) |
|
|
Focus system
|
Focus system: Coaxial coarse/fine focus system. Minimum division of fine focusing: 4μm |
Focus system : Coaxial coarse/fine focus system, with tension adjustable and up stop. Minimum division of fine focusing: 4μm |
|
Nosepiece |
Quadruple(Backward ball bearing inner locating) |
|
|
Stage |
Double layer mechanical(Size:125mmX115mm, Move range: 70mmX30mm) |
|
|
Abbe Condenser |
Abbe condenser with aperture diaphragm and filter seat. Rack & pinion adjustable N.A.1.25 |
|
|
Filter |
Blue filter |
|
|
Frosted filter |
||
|
Collector |
For halogen lamp |
|
|
Light source |
6Volt 20Watt Halogen lamp with brightness control |
|
Optional accessories
|
Name |
Sort/Technique parameter |
NO. |
|
|
Eyepiece |
Wide field WF16X(11mm) |
1051510 |
|
|
Dividing 10X(18mm) |
1021010 |
||
|
Eyepieces tube |
Monocular (Inclination of 45˚) |
010004 |
|
|
Trinocular (Inclination of 45˚) |
012201 |
||
|
Dual viewing tube (Inclination of 30˚) |
011002 |
||
|
Nosepiece |
Triple (Backward Ball bearing inner locating) |
030001 |
|
|
Stage |
Rotatable(diameter:¦µ120mm) |
041001 |
|
|
Fixed(Size:120mmX120mm, With single lens and iris diaphragm) |
040007 |
||
|
Filter |
Green filter |
115002 |
|
|
Yellow filter |
115003 |
||
|
Light source |
Fluorescent lamp |
5W,110V/220V Can be choose |
071004 |
|
Ordinary lamp |
110V/220V Can be choose |
072003 |
|
|
LED Collector |
High brightness white |
073004 |
|
|
Reflecting mirror |
Plane-concave reflecting mirror with stand |
074005 |
|
|
Camera |
Photography |
USB Output |
1096001 |
|
VIDEO Output |
1108001 |
||
|
Adapter(For LED illumination) |
Input: 230V~50/60HZ Output: 9V 500mA |
101001 |
|
|
Input: 110V~50/60HZ Output: 9V 500mA |
101002 |
||
|
Facility polarize |
Polarizer(360° rotatable) |
111001 |
|
