Description
Small
cubage, light weight, easy operation and wide range of accessories.
With bright field, dark field and polarization observation system.
Widely used for field metallurgical analysis and research in factories. Also
used for image and video analysis.
|
|
|
NY-2 |
|
Eyepiece |
10×/16 |
● |
|
Eyepiece with scale of cross hair 10× |
● |
|
|
12.5×/14 |
○ |
|
|
16×/12 |
○ |
|
|
Plan Achromatic Objective |
4×/0.10 WD 52.3mm |
● |
|
10×/0.20 WD 17.3mm |
● |
|
|
25×/0.40 WD 0.90mm |
● |
|
|
40×/0.65 WD 0.40mm |
● |
|
|
63×/0.85 WD 0.20mm |
● |
|
|
Zooming system |
0.8×、1×、1.25× |
● |
|
Adapter for Dark Field |
Adapter for objective 10× |
● |
|
Adapter for objective 25× |
● |
|
|
Viewing Head |
Sliding binocular viewing head |
● |
|
Kohler Incident Light |
12V/50W Halogen light, Center and brightness adjustable |
● |
|
Polarizer and analyzer |
● |
|
|
Stage |
Cycle-mechanical stage Φ160mm, Center adjustable, moving range12mm×16mm |
● |
|
Small stage：Φ10，Φ13，Φ15，Φ20，Φ21，Φ27 Stage: Φ10, Φ13, Φ15, Φ20, Φ21, Φ27 |
● |
|
|
Accessories |
Photo/Video attachment |
○ |
|
Micrometer scale 0.01mm |
● |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice.
