Item

O-I3

O-I3PH

Main Body

●

●

Eyepiece

WF10×／20mm

●●

●●

WF16×／13mm

○○

●●

10X Article Eyepiece (0.1mm)

○

●

Centering Eyepiece

●

●

LWD Plan Objective

LPL 2.5×／0.07

W.D.=29.7mm

○

○

LPL 4×／0.10

W.D.=17.5mm

○

●

LPL10×／0.25

W.D.=7.9mm

●

○

LPL25×／0.40

W.D.=5.0mm

●

●

LPL40×／0.65

W.D.=3.0mm

●

●

LWD Plan
Phase Contrast Objective

LPL Ph+ 10×／0.25

W.D.=7.9mm

○

●

LPL Ph+ 25×／0.40

W.D.=5.0mm

●

●

LPL Ph+ 40×／0.65

W.D.=3.0mm

○

●

Annular Spot 10X

○

●

Annular Spot 25X

●

●

Annular Spot 40X

○

●

Slide Relief Phase Contrast Condenser  N.A.0.35   W.D. =45mm

●

Turnable Relief Phase Contrast Condenser  N.A.0.35  W.D. =45mm

●

Seidentopf Trinocular Head: Inclined 45°
Both 100 (binocular tube) : 0 (photo tube) and 20 (binocular tube) : 80 (photo tube)

●

●

Mechanical stage available for 96 holes plate, moving range: 128（X）×80（Y）mm
Large Stage: 206 (X) X 170 (Y) mm

●

●

65mm Culture Dish Holder

●

●

54mm Culture Dish Holder

○

○

35mm Culture Dish Holder

●

●

Filter (Blue, Green, Gray)

●

●

1X C-mount

○

●

0.6X C-mount (focus adjustable)

○

○

12V/20W Halogen lamp

●

●

Micrometer (0.01mm)

○

○
