LED Cursor (Pointer)
In order to make the intercourse convenient between teacher and students, the microscope is equipped with LED cursor pointer to indicate image in the microscope viewing field, the pointer is Arrow type, and light intensity adjustable button is also equipped. The pointer can be moved freely and any position of the image can be indicated.
|
Specification |
MIC-8F2 |
MIC-F2A |
|
|
Viewing Head |
Dual viewing Compensation Free binocular head(55mm-75mm) |
● |
● |
|
Indicator |
LED cursor(Pointer) |
|
● |
|
Eyepiece |
WF10×/22mm |
● |
● |
|
Objective |
Infinity Achromatic 4×、10×、40×(s)、100×(s)Oil |
● |
● |
|
Stage |
Double layer mechanical stage Stage Size:180mm×150mmMoving Range:75mm×50mm |
● |
● |
|
Condenser |
N.A.1.25Abbe condenser with iris diaphragm and filter |
● |
● |
|
Focusing |
Coaxial coarse & fine focusing adjustment Fine focusing scale value0.002mm |
● |
● |
|
Light Source |
Halogen bulb 6V/20W, AC 220V/110V Fine focusing scale value0.002mm |
● |
● |
|
Optional Accessory |
Eyepiece：WF16×、WF20×、P16× |
||
|
Objective：20×、60(s)Infinity |
|||
|
Semi-plan Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil Infinity Plan Achromatic Objective:4×、10×、20×、40×(s)、60×(s)、100×(s)oil |
|||
|
Phase Contrast Attachment Photography attachment and CCD Adapter 0.5×、0.57×、0.75× |
|||
|
Compensation Free Binocular Head(48mm-75mm) |
|||
