Model

MIA-402

MIA-403

MIA-408

MIA-409

Viewing Body

Square 45°Incline Monocular Body

●

Square 45°Incline Dual Viewing body

●

30°Incline Binocular Body，Interpupillary Adjustable Distance:55mm～75mm

●

30°Incline Trinocular Body (2/8 Light Spectrum), Interpupillary Adjustable Distance:55mm～75mm

●

Eyepiece

WF10X (Viewing Field Diameter: ø18mm)

Objectives

Adjustable Parfocal Achromatic Objective 4×/NA 0.1，10×/NA 0.25，40×(s)/NA 0.65，100×(s, oil)/NA.1.25

Fixed Stage

Size:110mm×115mm，Moving Range:60mm×30mm，Venire Division:0.1mm

Nosepiece

Four Holes Plane Nosepiece

Condenser

Abbe Condenser: N.A.1.25, Elevating Range:15mm

Focusing

Separate Coaxial Coarse/Fine Focusing System.FineFocusAdjustmentRange: >2mm.CoarseFocusAdjustmentRange:20mm(with Coarse Focusing Spare Limiter And Knob Slipping Protection Unit)

Illumination

Incandescent lamp 220V/20W Or 110V/20W

●

●

●

●

Fluorescent Lamp 220V/5W Or 110V/5W

○

○

○

○

6V 20W Halogen Bulb, With Adjustable Brightness, Free Voltage 100V-240V

○

○

○

○
