Total Magnification: 4×-2000×

XSP-160

XSP-170

XSP-180

Viewing Head

Siedentopf binocular viewing head, inclined at 30°,360°rotatable, interpupillary distance 47-75mm

●

●

●

Siedentopf trinocular viewing head, inclined at 30°,360°rotatable,interpupillary distance 47-75mm

○

○

○

Eyepiece

Eyepiece WF10×18mm

●

Wide field eyepiece WF10×/20 mm

●

Super wide field eyepiece WF10×22mm

●

Wide field eyepiece 12.5×14mm

○

Wide field eyepiece 15×16mm

○

○

Wide field eyepiece 16×12mm

○

Wide field eyepiece 20×12mm

○

○

Objective

Semi plan achromatic objective 4X, 10X,40X,100X

●

Semi plan achromatic objective 20X, 60X

○

Infinite semi plan achromatic objective 4X, 10X,40X,100X

●

Infinite semi plan achromatic objective 20X, 60X

○

Infinite plan achromatic objective 4X, 10X,40X,100X

●

Infinite plan achromatic objective 20X, 60X

○

Nosepiece

Backward quadruple nosepiece

●

●

○

Backward quintuple nosepiece

○

○

●

Focusing

Coaxial coarse & fine adjustment, fine division 0.002mm, fine stroke 0.2mm per rotation, moving range 29mm

●

Coaxial coarse & fine adjustment, fine division 0.002mm, fine stroke 0.2mm per rotation, moving range 24mm

●

●

Stage

Double layer mechanical stage 156×138mm, cross travel 78×52mm, using low-positioned X/ Y coaxial control knob

●

Double layer mechanical stage 216×150mm, cross travel 78×52mm, using low-positioned X/ Y coaxial control knob

●

●

Condenser

Abbe condenser NA1.25 with aperture diaphragm

●

Illumination

3W LED light, brightness adjustable

●

●

●

5W LED light, brightness adjustable

○

○

○

Optional

Photo attachment,

○

○

○

Video attachment

○

○

○

Polarization set

○

○

○

Phase contrast kit

○

○

Dark field condenser (Dry)

○

○

○

Dark field condenser (Oil)

○

○

○

Kohler illumination

○

○

○

Epi-Fluorescent attachment

○

○
