MIC-NT6 series zoom stereo microscope
MIC-NT6 with a new optical system design, clear imaging field of view range increased dramatically, better resolution, better contrast; effectively reduce the work to make
With fatigue, increase comfort and operational efficiency was observed.
Innovative video integration design, it is the operator's eyes liberation, directly through the LCD screen on the work piece detection, no longer need to close the eyepiece longer
|
The new coating design , high quality optical systems , coated with a special layer of the optical member , is formed in a large field of view clear and bright images and flat |
|
Shift zoom lens 1X/3X, 2X/4X, 1X/2X |
|
Standard magnification 20X/40X, and other optional auxiliary lens magnification eyepiece , the magnification range:5X ~ 160X |
|
Standard working distance of100mm, creating enough space for the use of |
|
10X wide field eyepiece field of view reaches20mm, flat-field high eye point design , more suitable for search and observation |
|
Observe head 45 ° inclined binocular diopter adjustable , easy to operate and comfortable, prolonged use of a sense of fatigue |
|
Ergonomic design, hand wheel zoom level ( axial ) bilateral settings , zoom Repeatability |
|
Best eye point height , to ensure that different vision users can get a clear image of satisfaction |
Technical Specifications
|
magnification |
Standard configuration : 20X/40X optional eyepieces and auxiliary objective expandable 5X ~ 160X, vertical Direct Shift Zoom |
|
objective |
1X, 2X, 3X, 4X |
|
eyepiece |
high eye point wide field eyepiece WF10X/20mm |
|
high eye point wide field eyepiece WF15X/15mm |
|
|
high eye point wide field eyepiece WF20X/10mm |
|
|
observation head |
binocular head , 45 ° tilt , 360 ° rotation , interpupillary distance 54 ~76mm, bilateral diopter adjustment (± 5) |
|
Working Distance |
Standard configuration :100mm( effective distance ) optional auxiliary lens extended to30mm-165mm |
|
auxiliary lens |
0.5X/165mm, 1.5X/45mm, 2X/30mm |
|
focusing bracket |
focusing hand wheel adjustable elastic , lifting range50mm |
|
base |
variety of other base, ring lights , fluorescent lights, fiber optic lighting, etc. can be the first |
|
other optional |
mobile platform |
