With Infinite Optical System, Kohler Illumination, Providing Excellent Optical Quality and making Image Perfect.
With Low and Forward Position Coaxial Focus System, Focusing Knobs and Brightness Adjustable Knob within reaching Location, Stable Integral Structure, Reasonable Ergonomic Design, Making.
Operator Feel More Comfortable and Effective.
Features：
|
|
Comfortably observing with compensation free trinocular head Inclined at 30° Suitable for observer with wide interpupillary range of 48-75mm |
|
|
Larger viewing area with extra wide field eyepiece EW10×/ 22 Focus control with diopter adjustable |
|
|
Big operating space with backward quintuple nosepiece |
|
|
Rectangle double layers mechanical stage 185×142mm, moving range 75×55mm, comfortable operation with low position adjustable knobs |
|
|
Perfect image with infinite plan achromatic objective |
|
|
Overcoming illumination asymmetry at low magnification observation |
|
|
With aspherical condenser and Kohler illumination, providing enough, even and high contrast illumination for various objective observations. |
|
|
External illumination, halogen lamp 6V/ 30W, brightness adjustable, 24V/ 100W for optional |
Specification：
|
|
XSP-NY |
||
|
Viewing Head |
Seidentopf Trinocular Head |
● |
|
|
Tiltable Binocular/Trinocular Head |
○ |
||
|
Eyepiece |
Extra Wide Field Eyepiece EW10×/ 22 |
● |
|
|
Nosepiece |
Backward Quintuple Nosepiece |
● |
|
|
Backward Sextuple Nosepiece |
○ |
||
|
Infinite Plan Achromatic Objective |
4×, 10×, 40×, 100× |
● |
|
|
20× |
○ |
||
|
Objectives for Dark Field |
100× |
○ |
|
|
Condenser |
Swing-out Condenser NA 0.9/ 0.25 |
● |
|
|
Stage |
Double Layers Mechanical Stage 185×142/ 75×55 |
● |
|
|
Illumination |
External Illumination, Aspherical Collector, Halogen Lamp 6V/ 30W |
● |
|
|
External Illumination, Aspherical Collector, Halogen Lamp 24V/ 100W |
○ |
||
|
LED Illumination |
○ |
||
|
Photo Attachment |
|
○ |
|
|
Video Adapter |
C Mount 1× |
○ |
|
|
C Mount 0.5× |
○ |
||
|
Filter |
Blue Filter |
● |
|
|
Green Filter |
● |
||
|
Multi Viewing Attachments |
Multi Viewing Attachments for 5 persons |
○ |
|
|
Multi Viewing Attachments for 3 persons |
○ |
||
|
Multi Viewing Attachments for 2 persons |
○ |
||
|
Polarization Attachment |
○ |
||
|
Phase Contrast Kit |
Turret Phase Contrast Kit |
○ |
|
|
Dark Field Attachment |
○ |
||
|
Epi-fluorescent Attachment |
○ |
||
|
Temperature Controlled Stage |
○ |
||
|
Drawing Attachment |
○ |
||
|
NDFA-D Dark Field Condenser (Dry) |
NDFA-O Dark Field Condenser (Oil) |
|
|
|
|
NPHA Turret Phase Contrast Kit |
Polarization Attachment |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design
change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
