0.35 M pixel cmos economic camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
APTINA CMOS color |
|
Scan Mode |
Progressive |
|
Max. Resolution |
640 x 480 (Approx. 350,000 Pixels) |
|
Sensor Size (Diagonal) |
1/4“ (3.58mm(H) x2.69mm(V), Diagonal4.48mm) |
|
Pixel Size |
5.6μm x 5.6μm |
|
G Sensitivity |
1.9v/lux-sec(550nm) |
|
Dynamic Range |
60dB |
|
A/D Converter |
8-Bit R.G.B |
|
SN Ratio |
45dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
30fps @All Resolutions |
|
Binning |
N/A |
|
Exposure |
Electronic Rolling Snap(ERS), Auto |
|
White balance |
Auto |
|
Color Rendering Technique |
N/A |
|
Peak Quantum Efficiency |
N/A |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain , VFW |
|
Recording System |
Still Picture and Movie |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
1.3 M pixel cmos economic camera
|
HARDWARE CONFIGURATION |
||
|
Image Pickup Device |
APTINA CMOS color |
|
|
Scan Mode |
Progressive |
|
|
Max. Resolution |
1280 x 1024 (Approx. 1,300,000 Pixels) |
|
|
Sensor Size (Diagonal) |
1/3“ (4.60mm(H) x3.70mm(V), Diagonal5.9mm) |
|
|
Pixel Size |
3.6μm x 3.6μm |
|
|
G Sensitivity |
1.0v/lux-sec(550nm) |
|
|
Dynamic Range |
71dB |
|
|
A/D Converter |
8-Bit R.G.B |
|
|
SN Ratio |
44dB |
|
|
Spectral Range |
380-650nm (with IR-filter) |
|
|
Video Format & Frame Rate |
7.5fps @1280 x 1024, 12.5fps @1024 x 768, 800 x 600, 30fps @Other Resolutions |
|
|
Binning |
N/A |
|
|
Exposure |
Electronic Rolling Snap(ERS), Auto |
|
|
White balance |
Auto |
|
|
Color Rendering Technique |
N/A |
|
|
Peak Quantum Efficiency |
N/A |
|
|
Readout Noise |
N/A |
|
|
Extinction Ratio |
N/A |
|
|
Smear |
N/A |
|
|
Capture/Control API |
DirectShow , Twain , VFW |
|
|
Recording System |
Still Picture and Movie |
|
|
OPERATING ENVIRONMENT |
||
|
Operating Temperature |
-10℃~50℃ |
|
|
Storage Temperature |
-20℃~60℃ |
|
|
Operating Humidity |
30~80%RH |
|
|
Storage Humidity |
10~60%RH |
|
|
Power Supply |
DC 5V over PC USB port |
|
|
SOFTWARE ENVIRONMENT |
||
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) |
|
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
|
Memory:2GB or more |
||
|
USB port:USB2.0 High-speed Port |
||
|
Display:17" or larger |
||
|
CD-ROM |
||
2 M pixel cmos economic camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
APTINA CMOS color |
|
Scan Mode |
Progressive |
|
Max. Resolution |
1600 x 1200 (Approx. 2,000,000 Pixels) |
|
Sensor Size (Diagonal) |
1/3.2“ (4.73mm(H) x3.52mm(V), Diagonal5.90mm) |
|
Pixel Size |
2.8μm x 2.8μm |
|
G Sensitivity |
1.0v/lux-sec(550nm) |
|
Dynamic Range |
71dB |
|
A/D Converter |
8-Bit R.G.B |
|
SN Ratio |
42.3dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
5fps @1600 x 1200, 7.5fps @1280 x 1024, 1280 x 960, 20fps @800 x 600, 30fps @ Other Resolutions |
|
Binning |
N/A |
|
Exposure |
Electronic Rolling Snap(ERS), Auto |
|
White balance |
Auto |
|
Color Rendering Technique |
N/A |
|
Peak Quantum Efficiency |
N/A |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain , VFW |
|
Recording System |
Still Picture and Movie |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
3 M pixel cmos economic camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
APTINA CMOS color |
|
Scan Mode |
Progressive |
|
Max. Resolution |
2048 x 1536 (Approx.3,200,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2.7“ (4.506mm(H) x3.379mm(V), Diagonal5.632mm) |
|
Pixel Size |
2.2μm x 2.2μm |
|
G Sensitivity |
1.0v/lux-sec(550nm) |
|
Dynamic Range |
61dB |
|
A/D Converter |
8-Bit R.G.B |
|
SN Ratio |
43dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
3fps @2048 x 1536, 5fps @1600 x 1200, 7.5fps @1280 x 1024, 30fps @Other Resolutions |
|
Binning |
N/A |
|
Exposure |
Electronic Rolling Snap(ERS), Auto |
|
White balance |
Auto |
|
Color Rendering Technique |
N/A |
|
Peak Quantum Efficiency |
N/A |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain , VFW |
|
Recording System |
Still Picture and Movie |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
5 M pixel cmos economic camera
|
HARDWARE CONFIGURATION |
|
|
Image Pickup Device |
APTINA CMOS color |
|
Scan Mode |
Progressive |
|
Max. Resolution |
2592 x 1944 (Approx.5,200,000 Pixels) |
|
Sensor Size (Diagonal) |
1/2.5“ (5.70mm(H) x4.28mm(V), Diagonal7.13mm) |
|
Pixel Size |
2.2μm x 2.2μm |
|
G Sensitivity |
0.53v/lux-sec(550nm) |
|
Dynamic Range |
66.5dB |
|
A/D Converter |
8-Bit R.G.B |
|
SN Ratio |
40.5dB |
|
Spectral Range |
380-650nm (with IR-filter) |
|
Video Format & Frame Rate |
2fps @2592 x 1944, 3fps @2048 x 1536, 5fps @1600 x 1200, 7.5fps @1280x1024, 30fps @Other Resolutions |
|
Binning |
N/A |
|
Exposure |
Electronic Rolling Snap(ERS), Auto |
|
White balance |
Auto |
|
Color Rendering Technique |
N/A |
|
Peak Quantum Efficiency |
N/A |
|
Readout Noise |
N/A |
|
Extinction Ratio |
N/A |
|
Smear |
N/A |
|
Capture/Control API |
DirectShow , Twain , VFW |
|
Recording System |
Still Picture and Movie |
|
OPERATING ENVIRONMENT |
|
|
Operating Temperature |
-10℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Operating Humidity |
30~80%RH |
|
Storage Humidity |
10~60%RH |
|
Power Supply |
DC 5V over PC USB port |
|
SOFTWARE ENVIRONMENT |
|
|
Operating System |
Microsoft®Windows®XP /Vista/ 7 / 8 (32 & 64 bit) |
|
PC Requirements |
CPU: Equal to Intel Core2 2.8GHz or higher |
|
Memory:2GB or more |
|
|
USB port:USB2.0 High-speed Port |
|
|
Display:17" or larger |
|
|
CD-ROM |
|
