XSZ-EF40 Biological fluorescence Microscope
■Infinity color corrected optical system, new upgraded Koehler illumination system, presents a clear & bright micro-image under each magnification.
■ Fire-new ergonomic design, steady system structure, easy operation, is suitable for various working environments.
■"Building blocks" design for combining multiple functions, fluorescence, phase contrast, polarizing, dark field attachments can be assembled on the basis of bright field observation.
■Widely apply to clinical diagnosis, teaching experiment, pathological test and other micro-fields.
Series specifications
|
Optical system |
Infinity color corrected optical system |
|
|
Viewing head |
Efficient infinity binocular head, 30°-60° elevation adjustable; 360° rotatable; interpupillary adjustable distance: 54-75mm; diopter +/-5 adjustable. |
|
|
30° inclined binocular head; 360° rotatable; interpupillary adjustable distance: 54-75mm; diopter +/-5 adjustable. |
||
|
30° inclined trinocular head, splitting ratio R:T=50:50; 360° rotatable; interpupillary adjustable distance: 54-75mm; diopter +/-5 adjustable. |
||
|
30° inclined trinocular head (special for fluorescence), splitting ratio R:T=100:0 or 0:100; 360° rotatable; interpupillary adjustable distance: 54-75mm; diopter +/-5 adjustable. |
||
|
30° inclined digital binocular head; 360° rotatable; interpupillary adjustable distance: 54-75mm; diopter +/-5 adjustable. |
||
|
Eyepiece |
High eye-point wide field plan eyepiece PL10x22mm, reticle can be assembled. |
|
|
High eye-point wide field plan eyepiece PL15x16mm |
||
|
Objective |
Infinity plan achromatic objectives (2X,4X,10X,20X,40X,100X) |
|
|
Infinity plan phase contrast objectives (10X,20X,40X,100X) |
||
|
Infinity plan semi-achromatic fluorescence objectives (4X,10X,20X,40X,100X) |
||
|
Nosepiece |
Revolving quadruple nosepiece/ quintuple nosepiece |
|
|
Body |
Coaxial focus system with upper limited and tension adjustment; coarse range:30mm; fine precision:0.002mm; focus height adjustable. |
|
|
Stage |
175x145mmdouble layer mechanical stage, rotatable; with special fabrication processing, anti-corrosive and anti-friction; X,Y moving hand wheel in right or left hand; moving range: 76x50mm, precision :0.1mm. |
|
|
187x166mmdouble layer mechanical stage, moving range: 80x50mm, precision:0.1mm. |
||
|
Condenser |
N.A.0.9swing-out type achromatic condenser；N.A.1.2/0.22 swing-out type achromatic condenser；N.A.1.25 quintuple phase contrast condenser；N.A.0.9 dry dark field condenser；N.A.1.25 oil dark field condenser. |
|
|
Reflected fluorescence illumination system |
XYRFLP reflected fluorescence Koehler illumination with alterable field diaphragm and aperture diaphragm (center adjustable). |
|
|
XYLH100HG mercury lamp house with viewfinder; the center and focal length of viewfinder &filament are adjustable. |
||
|
U2-RFLT100 digital power control box of mercury lamp, wide voltage: 90-245VAC. |
||
|
Imported OSRAM 100W DC mercury bulb; disc fluorescence filers: UV/VB/G; 30ND25-RFLP attenuation plate. |
||
|
Transmitted illumination system |
Wide voltage: 100-240V, built-in transmitted Koehler illumination; 6V/30W halogen, pre-centered, intensity adjustable. |
|
|
Polarizing kit |
Analyzer 360° rotatable; polarizer and analyzer can be out of light path. |
|
|
Filter |
Yellow, green, blue, neutral filter |
|
|
Light splitting device |
R:T=70:30 or 100:0, special 1x CTV |
|
|
Camera adapter |
0.5xCTV, 0.67xCTV, 1xCTV |
|
|
|
||
