MIC TECH’S new advanced XJP-8A inverted bright & dark field metallurgical microscope is designed with infinite optical system,wide field eyepiece and long working distance bright & dark field infinite plan objectives and polarization device.As a large scientific research level metallurgical microscope,it meets the demand of all kinds of physio-chemical analysis and inspection.It can be equipped with microscopic photography & video and image analysis system.The instrument can be used in metallurgic examination and analysis and the research work of surface coating,crack and so on.
|
Parts |
Order No. |
Specification |
XJP-8A |
|
Frame |
XJP-8A |
Humanity Design, Stable Reliable. |
● |
|
Seidentopf |
MS1 |
Binocular Tube, Interpupillary distance 47-78mm, 45°inclined diopter adjustable. |
● |
|
MS1AT |
Trinocular Tube, Interpupillary distance 47-78, 45°inclined diopter adjustable. |
○ |
|
|
E1022PC |
Plan Eyepiece, WF10X/22, and diopter adjustable. |
○○ |
|
|
E1025PA |
Plan Eyepiece, WF10X/25 |
○○ |
|
|
Objectives |
WB-P4C |
infinity plan working distance B&D objective 5×/0.15（W.D.14.47mm） 10×/0.25（W.D.16.01mm） 20×/0.40（W.D.10.5mm） 50×/0.55（W.D.5.1mm） |
○ |
|
|
M-OLPi10 |
10×infinite long distance plan objective NA=0.25 WD=18.48 |
● |
|
|
M-OLPi20 |
20×infinite long distance plan objective NA=0.40 WD=8.35 |
● |
|
|
M-OLPi40 |
40×infinite long distance plan objective NA=0.65 WD=3.895 |
● |
|
|
M-OLPi50 |
50×infinite long distance plan objective NA=0.70 WD=7.9mm |
● |
|
|
M-OLPi80 |
80×infinite long distance plan objective NA=0.80 WD=0.848 |
● |
|
|
M-OLPid10 |
10×infinite long distance plan dark field objective NA=0.25 WD=18.48 |
● |
|
|
M-OLPid20 |
20×infinite long distance plan dark field objective NA=0.40 WD=8.35 |
○ |
|
|
M-OLPid40 |
40×infinite long distance plan dark field objective NA=0.65 WD=3.895 |
● |
|
|
M-OLPid50 |
50×infinite long distance plan dark field objective NA=0.70 WD=1.95 |
○ |
|
|
M-OLPid80 |
80×infinite long distance plan dark field objective NA=0.80 WD=0.848 |
○ |
|
Lamp House |
DX10 |
12V100W Halogen Lamp House |
● |
|
Power Box |
DYX4 |
12V100W Halogen Power Box |
○ |
|
DYX2 |
12V50W Halogen Power Box |
● |
|
|
Stage |
ZT1 |
Fixed Stage, Size: 240mmX260mm, Movement Range: 135mmX85mm. X/Y Coaxial Flexible Knobs On The Bottom Side. |
○ |
|
ZT1-1000 |
Specimen Holder(φ118) |
● |
|
|
ZT1A |
Mechanical Stage, Size: 350mm×208mm, Movement Range: 50mmX50mm. |
● |
|
|
Specimen Clamps |
YPQ1 |
Specimen Clamps |
○ |
|
Revolving Nosepiece |
ZQ580A |
Sextuple Revolving Nosepiece, |
● |
|
Illuminator |
DLST1 |
Multifunctional Reflected Light Illuminator |
● |
|
JXMKBG |
Brightfield Module |
● |
|
|
Filter |
LA3-0011 |
Blue Filter |
● |
|
LU3-0011 |
Green Filter |
● |
|
|
LH3-0011 |
Yellow Filter |
● |
|
|
LAB3-0011 |
50% Cutting Filter |
● |
|
|
Polarization Kits |
PQ2 |
Polarizer |
● |
|
PY3 |
Analyzer |
● |
|
|
C-Mount |
SX1 |
0.5X C-Mount |
● |
|
SX5 |
0.25X C-Mount(Fit 1/3'CCD) |
○ |
|
|
Illumination Bulb |
BZ-0022E |
12V50W Osram Halogen Bulb |
○ |
|
BZ-0022D |
12V50W Halogen Bulb |
●●● |
|
|
Other |
BZ-0023A |
250V/5A Φ5X20 Fuse |
●●● |
|
OMMM |
Metallurgical Micrometer |
● |
|
|
DLSS1-0029 |
Diaphragm Adjusting Handle |
●● |
|
|
BZ2-0018 |
φ2mm Allen Screw Driver |
● |
|
|
BZ1-0018 |
φ2.5mm Allen Screw Driver |
● |
|
|
BZ1-0018A |
φ3mm Allen Screw Driver |
● |
|
|
BZ-0021 |
Power Cord |
● |
