XSZ-N2 serials microscope are with high efficiency, flexibility and stability are the characters of this series microscope. It is specially developed for various applied scopes. It is widely used, from daily work to scientific research, in Laboratory, Hospitals and Colleges. Because of higher capability with lower price and humanized configuration design, It also becomes the first choice of individual, Schools, and Scientific research organization.
Features:
1. Wide-field Eyepiece, high light illumination and superior optical parts make
the image clear, sharp and bright.
2. Backward nosepiece with superior objectives makes the best viewing effect
and more space for the operator.
3. Wide mechanical stage with 2-Microslide specimen clamp provides more convenience
for the observer.
4. High precision focusing adjustment system and humanized configuration design
provide operator more comfortable.
5. Frontal undrawing type Light collector framework, makes the user change the
bulb more quickly and easily.
|
Specification |
XSZ-N2 |
XSZ-N2T |
XSZ-N2A |
XSZ-N2AT |
|
|
Head |
Compensation Free Binocular Head. Inclined at 30 ° |
● |
|
● |
|
|
Compensation Free Trinocular Head. Inclined at 30 ° |
|
● |
|
● |
|
|
Interpupillary Distance55mm-75mm |
● |
● |
● |
● |
|
|
Eyepiece |
WF10 ×/18mm |
● |
● |
|
|
|
WF10 ×/22mm |
|
|
● |
● |
|
|
Objective |
Achromatic objective: 4 × ,10 × ,40 ×(S),100 ×(S)Oil |
● |
● |
|
|
|
Infinity objective: 4 × 10 × 40 × (S) 100 × (S)Oil |
|
|
● |
● |
|
|
Stage |
Double layers mechanical stage |
● |
● |
● |
● |
|
Stage size:180mm×150mm |
|||||
|
Moving range:75mm×50mm |
|||||
|
Condenser |
N.A1.25 Abbe condenser with iris diaphragm & filter |
● |
● |
● |
● |
|
Swing type N.A1.25 Abbe condenser with iris diaphragm & filter |
○ |
○ |
○ |
○ |
|
|
Focusing |
Coaxial coarse & fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value0.002mm |
● |
● |
● |
● |
|
Collector |
High brightness Kohler illumination |
● |
● |
● |
● |
|
Light source |
Halogen tungsten bulb 12V/20W.AC 85V-230V |
● |
● |
● |
● |
|
Adjustable brightness |
|||||
|
Optional |
Eyepiece：WF16×、WF20×、P16× and 1.3 or 3.0 Mega pixels CMOS electronic eyepieces |
||||
|
Plan-Objective：2×、4×、10×、20×、40×(s)、60×(s)、100×(s) |
|||||
|
Infinity-plan Objective:2×、4×、10×、20×、40×(s)、60×(s)、100×(s) |
|||||
|
Phase Contrast Attachment |
|||||
|
Simple Polarization Set |
|||||
|
Photo and CCD attachment |
|||||
