Model J-Y1 series Inverted Biological Microscope with its excellent optical capability ,wide application, firm body frame and skillful figure design, meet the demands of biology, microbiology, histology immunology and etc.
This inverted biological microscope provides excellent functions .High resolution and contrast long working distance objectives provide high quality image. High contrast Phase contrast objectives make the figure and configuration of the cells more clear .The long working distance condenser can contain higher vessels or samples.
The stable & reliable “T” type base, streamline figure design, simple and convenient operating system makes your work easy and relax.
|
Specification |
J-Y1 |
J-Y1T |
J-Y1A |
J-Y1AT |
|||||
|
Viewing head |
Compensation free Binocular Head .Inclined at 4 5 ° (50mm-75mm) |
● |
|
● |
|
||||
|
Compensation Free Trinocular Head .Inclined at 45 ° (50mm-75mm) |
|
● |
|
● |
|||||
|
Eyepiece |
WF10X/20mm |
● |
● |
|
|
||||
|
WF10X/22mm |
|
|
● |
● |
|||||
|
WF10X/18mmwith Cross graduation of0.1mmscale |
○ |
○ |
○ |
○ |
|||||
|
Objective |
Long working distance plan-objective |
LWDPL4X/0.1W.D.25mm |
● |
● |
|
|
|||
|
LWDPL10X/0.25 phase contrast W.D.11mm |
|||||||||
|
LWDPL20X/0.4 phase contrast W.D.6mm |
|||||||||
|
LWDPL40X/0.6W.D.3.8mm |
|||||||||
|
Distance infinity plan-objective |
LWDPL4X/0.1W.D .29.4mm |
|
|
● |
● |
||||
|
LWDPL10X/0.25 phase contrast W.D.16mm |
|||||||||
|
LWDPL20X/0.4 phase contrast W.D .10.5mm |
|||||||||
|
LWDPL40X/0.6W.D .5.4mm |
|||||||||
|
Long working distance objective |
LWDPL10X |
○ |
○ |
○ |
○ |
||||
|
LWDPL20X |
● |
● |
● |
● |
|||||
|
Long working distance phase contrast objective |
LWDPL40X |
○ |
○ |
○ |
○ |
||||
|
Stage |
Double layers mechanical stage |
● |
● |
● |
● |
||||
|
Stage size: 242mmx172mm |
|||||||||
|
Central stage: Φ110mm |
|||||||||
|
Moving range:115mm×75mm |
|||||||||
|
Condenser |
N.A0.3Abbe condenser W.D.75mm |
● |
● |
● |
● |
||||
|
Focusing |
Coaxial coarse&fine focusing adjustment with rack and pinion mechanism Fine focusing scale Value0.002mm |
● |
● |
● |
● |
||||
|
Phase contrast sliding plate |
Center of phase contrast ring plate adjustable |
● |
● |
● |
● |
||||
|
Centering telescope |
Centering telescope |
● |
● |
● |
● |
||||
|
Filter |
Blue, green, yellow and frosted glass |
● |
● |
● |
● |
||||
|
Light source |
Halogen bulb12V/30W |
● |
● |
● |
● |
||||
|
Adjustable brightness |
● |
● |
● |
● |
|||||
|
Fluorescence attachment B.G Wave band ,220V(110V)/100W Mercury lamp |
○ |
○ |
○ |
○ |
|||||
|
Photography attachment |
Photograph connecting tube, adapter with MD or PK mount ,4X photograph eyepiece |
○ |
○ |
○ |
○ |
||||
|
Electron Eyepiece |
1.3 or 3.0Mega pixels CMOS electronic eyepiece |
○ |
○ |
○ |
○ |
||||
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design
change: To keep pace with technological advances, we have reserved the right to
make design modification and changes without notice.
