Model |
L-I2 |
|
Eyepiece |
Wide field WF10X(20mm) |
|
Objective |
Long working distance plan achromatic PL L 10X/0.25 |
|
Long working distance plan achromatic PL L 25X/0.40 |
|
|
Long working distance plan achromatic PL L 40X/0.60 |
|
|
Long working distance plan achromatic phase contrast objective PL L 10X/0.25 PHP2 |
|
|
Eyepiece tube |
Trinocular (Inclination of 30°, 100% image light for photography capable) |
|
Focus system |
Coaxial coarse/fine focus, with tensional adjustable and up stop minimum division of fine focusing: 2μm. |
|
Nosepiece |
Quadruple(Ball bearing inner locating) |
|
Stage |
Double layer mechanical(Size:224mmX208mm,moving range:112mmX79mm) |
|
Shelf of specimen |
Match to install ¦µ68mmor 77mmX29mmculture utensil |
|
Match to install 82mmX57mmculture utensil |
|
|
Match to install 128mmX85mm96 holes culture utensil |
|
|
Filter |
Blue filter |
|
Green filter |
|
|
Frosted filter |
|
|
Sliding phase contrast unit |
Centering telescope |
|
10X Sliding phase plate |
|
|
Condenser Rack & pinion adjustable, NA=0.4,working distance:50mm |
|
|
Light source |
6V 30W Halogen lamp with brightness control. |
|
Optional accessories |
Sort/Technique parameter |
NO. |
|
|
Eyepiece |
Wide field WF16X(11mm) |
1051016 |
|
|
Dividing 10X(20mm),0.1mm/Div |
1120010 |
||
|
Nosepiece |
Quintuple(Ball bearing inner locating) |
032001 |
|
|
Condenser |
Ultra long working distance,W.D.:70mm |
050006 |
|
|
Filter |
Yellow filter |
115003 |
|
|
Sliding phase contrast unit |
Objectives |
Long working distance plan achromatic phase contrast objective PL L 25X/0.40 PHP2 |
2430325 |
|
Long working distance plan achromatic phase contrast objective PL L 40X/0.60 PHP2 |
2430340 |
||
|
Sliding phase plate |
25X/40X |
112005 |
|
|
CCD adapter |
0.4X |
812001 |
|
|
0.5X |
812004 |
||
|
1X |
812002 |
||
|
0.5X with dividing0.1mm/Div |
812003 |
||
|
Camera |
DV-1(With USB & video output) |
800001 |
|
|
DV-2(With USB output) |
800003 |
||
|
DV-3(With video output) |
800005 |
||
|
Digital camera adapter |
CANON digital camera adapter(A610,A620,A630,A640) |
821001 |
|
|
Photograph unit |
2.5X/4X Change over photograph attachment with 10X viewing eyepiece |
840001 |
|
|
4X Focusing photograph attachment |
840002 |
||
|
MD Adapter |
840003 |
||
|
PK Adapter |
840004 |
||
