Item |
Specifications |
|||
|
Microscopy body |
MIC-645 |
MIC-660 |
MIC-645TR |
|
|
MIC-645 |
Magnification |
0.67x ~ 4.5x |
||
|
MIC-660 |
Zoom ratio |
6.7 : 1 |
||
|
MIC-645TR |
Working distance |
110mm |
||
|
Tube inclination angle |
45° |
60° |
45° |
|
|
Interpupillary |
Left / right interlocked |
|||
|
distance adjustment |
Adjustment range : 55 to75mm |
|||
|
Video camera adaptability |
- |
C-mount(0.5x built in) |
||
|
Click stop |
- |
Click stop for each zoom magnification: On-Off switching possible |
||
|
Auxiliary objective lens |
Mounting by screwing into the thread at the bottom of frame(M48 thread x0.8) |
|||
|
Stand |
MIC-ILST6 |
MIC-ILST6 |
||
|
MIC-ST6 |
|
Standard large stand |
LED reflected / transmitted illumination large stand |
|
|
MIC-ILST6 |
Frame installation |
Mounting diameter :76mm |
||
|
Focusing adjustment |
Knob rotation tension adjustment |
|||
|
Focusing stroke:120mm |
||||
|
Stage plate |
MIC-SPG |
MIC-SPG |
||
|
MIC-SPBW |
|
|||
|
Light source |
|
Transmitted illumination: LED |
||
|
|
Reflected illumination: LED |
|||
|
|
Average LED life span:10,000 hrs. |
|||
|
|
Input rating: AC 100-240V, 50/60Hz, 10W |
|||
|
Eyepieces |
MIC-EPA10x |
10x / FN 22 / Diopter adjustment:-8D~+5D / Eyepiece micrometer dist mountable |
||
|
MIC-EPA15x |
15x / FN 16 / Diopter adjustment:-8D~+5D / Eyepiece micrometer dist mountable |
|||
|
MIC-EPA20x |
20x / FN 12.5 / Diopter adjustment:-8D~+5D / Eyepiece micrometer dist mountable |
|||
|
Dimensions / Weight |
Dimension (W*D*H):289.9 x 329.9 x 371.3 / Weight:5.2Kg |
|||
