Order No.

Item

MA1000

MA1002

MA1003

MA2001

MA2002

MA1000

Reflecting Main Body

●

●

●

MA2000

Transmitting and Reflecting Main Body (Build In Transmit Light Source 6V30W)

●

●

13Q.2

Trinocular / With Analyzer

●

13QA.1

Trinocular

●

LH01

Lamp Housing / Reflected light source (12V50W)

●

●

●

●

●

3J.12

Power supply unit/ Reflected power source (12V50W)

●

●

●

●

●

II10

Ring slit illumination unit/four holes

●

●

●

●

●

II11

Dark Field Illumination unit with Dark Field Pulling Plate

○

○

○

○

○

S32

Stage for reflected light only for reflection Illumination

●

●

●

S33

Double-duty Stage

For Transmitted and reflected light

●

●

S34

Large Stage (100mm×120mm) with metal and glass stage and metal stage with holes

○

●

○

●

M-OPr10

10X Plan Achromatic Objective PL 10/0.25

●

●

○

○

M-OPr20

20X Plan Achromatic Objective PL 20/0.3(s)

●

●

○

○

M-OPr40

40X Plan Achromatic Objective PL 40/0.65(s)

●

●

○

○

M-OPOr100

100X Plan Achromatic Objective (oil) PL 100/1.25 Oil(s)

●

●

○

○

B-OPr

44X Plan Achromatic Objective PL4/0.10

○

○

○

○

B-OPr10

10X Plan Achromatic Objective PL 10/0.25(s)

●

●

B-OPr25

25X Plan Achromatic Objective PL 25/0.4(s)

●

●

B-OPr40

40X Plan Achromatic Objective PL 40/0.65(s)

●

●

B-OSPor100

100X Plan Achromatic Objective

(Oil) PL 100/1.25Oil(s)

●

●

M-OPd10

10X Dark Field Plan Objective Only Combine with II11

○

○

○

○

M-OPd20

20X Dark Field Plan Objective Only Combine with II11

○

○

○

○

M-OPd40

40X Dark Field Plan Objective Only Combine with II11

○

○

○

○

M-OLPi10

Infinite Far 10×Long Distance Plan Objective LPL 10×/0.25 WD=18.5

●

M-OLPi20

Infinite Far 20×Long Distance Plan Objective LPL 20×/0.4 WD=8.34

●

M-OLPi40

Infinite Far 40×Long Distance Plan Objective LPL 40×/0.65 WD=3.90

●

M-OLPi50

Infinite Far 50×Long Distance Plan Objective LPL 50×/0.70 WD=1.95

●

M-OLPi80

Infinite Far 80×Long Distance Plan Objective LPL 80×/0.80 WD=0.85

●

EW10

10X Wide Eyepiece WF16×-20

●●

●●

●●

●●

●●

EW16

16X Wide Eyepiece WF16×-14

○○

○○

○○

○○

○○

11X.10.2

Transmitted Light Bright Field Condenser Only Combine with S33

●

18X.1

Transmitted Light Dark Field Condenser Only Combine with S33

○

Epr10b

10X graduated ocular WF10×-18

○

○

○

○

○

2Q.3.1.2

Polarizer for Transmitted Light Only Combine with S33

○

18X.2

Phase Condenser

○

Only Combine with S33

B-OPpr10

10X Phase Objective

○

Only Combine with S33

B-OPpr40

40X Phase Objective

○

Only Combine with S33

B-Opopr 100

100X Phase Objective

○

Only Combine with S33

B-OPnr10

10X Phase Objective

○

Only Combine with S33

B-OPnr40

40X Phase Objective

○

Only Combine with S33

B-OPonr

100

100X Phase Objective

○

Only Combine with S33

EC8

Centering Eyepiece Only Combine with S33

○

3J.14

Planishing Tool

○

○

○

○

○

11X.11

35mm Camera Adapter Combine with proper photo eyepiece

○

○

○

○

EPHn4

4X Photo Eyepiece

○

○

○

○

EPHn2.5

2.5X Photo Eyepiece

○

○

○

○

EPHn6.3

6.3X Photo Eyepiece

○

○

○

○

135 Camera and Shutter Release

○

○

○

○

TV09b

TV

○

CU43-2

Digital Adapter C mount Suit to DV02 or others C mount adapter

○

○

○

○

DV02

Digital Adapter C mount Suit to TV09c

○

12X.13

Wire for power source For Transmitted Light Source

●

●

0.01mm Micrometer

○

○

○

○

○

Stage micrometer (division 0.01mm)

○

○
