FEATURES：
Fully coated optical system. Mechanical Tube length160mm, Compensation Free Binocular Head, Interpupillary Distance 55-75mm, 360°Rotatable45mmAchromatic Objectives. Parfocal Double Layers Mechanical Stage: Stage Size 120X125mm, Moving Range 60X30mm
Coaxial Coarse and Fin Focus Adjustment: Range12mm, Division to Fine Focus Adjustment0.002mm
Focusing Stop to Prevent Objectives & Slides from Damaging
Rack and pinion Adjustment for Condenser
Built-in Illumination, Adjustable Brightness
Power Supply 110V or 220V, CE Approval
A Wide Range of Accessories to be Equipped with this Microscope for multi-purpose
|
Specifications |
Model |
|||
|
XSZ-N15 |
XSZ- N15A |
XSZ- N15B |
||
|
Viewing Head 360°Rotatable |
Monocular Head Inclined at 30° |
○ |
○ |
|
|
Compensation Free Binocular Head Inclined at 30° |
|
○ |
○ |
|
|
Eyepiece |
WF10X,P16X(W16X) |
○ |
○ |
○ |
|
Objective |
Achromatic Objective 4x,10X,40X(S),100X(S)oil |
○ |
○ |
○ |
|
Stage |
Mechanical stage size:13 5×135mm |
○ |
○ |
○ |
|
Condenser |
Abbe NA 1.25 condenser with Iris Diaphragm ＆ Filter |
○ |
○ |
○ |
|
Focusing |
Coaxial coarse ＆Fine Focus Adjustment |
○ |
○ |
○ |
|
Illumination |
Built-in illumination Halogen Lamp 6V/20W ＆Adjustment Brightness |
○ |
○ |
○ |
|
Selective parts |
Objective:20X(S) 60X(S) |
|||
