2
In this model there is an angle of 45° between optical axis and plane of LCD screen, and this will be more comfortable for sitting person to view.
Features
|
Power supply |
5V DC（camera model and video model）/ USB port（ PC model） |
|
Tube size |
23.20mm or 30.00mm |
|
Connection |
Ocular tube or C-mount |
|
Uniform focusing |
Yes |
|
Optical magnification |
10X |
|
Image output |
SD card、USB port、AV socket |
|
Functions of camera |
Keyboard controlling |
|
Functions of PC camera |
Software controlling |
|
Functions of video camera |
TV setting |
|
USB cable |
1.5 m |
|
AV cable |
1.5 m |
|
Weight of device |
0.18kg |
Specifications
|
Sensor parameter |
2.0 Mega pixel CMOS interpolation to 5M |
|
LCD size |
3.6” TFT |
|
Resolution of camera |
2560x1920、2048x1536、1600x1200 |
|
Digital zoom |
8X |
|
Format of picture |
JPEG 、BMP、PNG |
|
Format of video |
WMV、AVI |
|
Flash memory |
8M |
|
Extra memory |
SD |
|
USB port |
USB2.0 |
|
Resolution of USB model |
640*480 |
|
TV system of AV model |
N or P |
|
White balance |
Auto |
Packing message:
1. Single box: Weight: 0.778 kg, Measurement: 20.0*14.5*11.5 ㎝³;
2. One carton of 20PCS: Weight: 16.68 kg,
Measurement: 69.0*32.0*36.0 ㎝³;
In this model the LCD screen is fixed vertically with optical axis, and in this way it is suitable for view of standing person.
Features
|
Power supply |
5V DC（camera model and video model）/ USB port（ PC model） |
|
Tube size |
23.20mm or 30.00mm |
|
Connection |
Ocular tube or C-mount |
|
Uniform focusing |
Yes |
|
Optical magnification |
10X |
|
Image output |
SD card、USB port、AV socket |
|
Functions of camera |
Keyboard controlling |
|
Functions of PC camera |
Software controlling |
|
Functions of video camera |
TV setting |
|
USB cable |
1.5 m |
|
AV cable |
1.5 m |
|
Weight of device |
0.18kg |
Specifications
|
Sensor parameter |
2.0 Mega pixel CMOS interpolation to 5M |
|
LCD size |
3.6” TFT |
|
Resolution of camera |
2560x1920、2048x1536、1600x1200 |
|
Digital zoom |
8X |
|
Format of picture |
JPEG 、BMP、PNG |
|
Format of video |
WMV、AVI |
|
Flash memory |
8M |
|
Extra memory |
SD |
|
USB port |
USB2.0 |
|
Resolution of USB model |
640*480 |
|
TV system of AV model |
N or P |
|
White balance |
Auto |
Packing message:
1. Single box: Weight: 0.778 kg, Measurement: 20.0*14.5*11.5 ㎝³;
2. One carton of 20PCS: Weight: 16.68 kg, Measurement: 69.0*32.0*36.0 ㎝³;
