With high eye point and wide field eyepiece SWH10X(Φ23mm),
the diameter of fitting : Φ30mm
Objectives :1X/2X、1X/3X、2X/4X，working distance :105mm
Total magnification 10X/20X，10X/30X，20X/40X (standard outfits)
Interpupillary distance adjustment range52mm~76mm
Diopter adjustment : ±6°(left drawtube)
The range of adjusting the focus is50mm(the square post is100mm)
The diameter of the round post : Φ25mm
The measurement to match between the support and the main body is Φ76mm
The distance between from the post center to the main body center is140mm
The diameter of the center working stage is Φ95mm
Illuminators：the down illuminator is the transmitted illumination of the fluorescent lamp(5W),the up illuminator is the reflected illumination of the halogen lamp(6V、10W).
Standard specification：
|
|
TM-12 |
TM-13 |
TMS124 |
|
Main body TS112 |
● |
|
|
|
Main body TS113 |
|
● |
|
|
Main body TS124 |
|
|
● |
|
Eyepieces SWH10X |
●● |
●● |
●● |
|
Eye shields |
●● |
●● |
●● |
|
Stand SD1 |
● |
● |
● |
Technical data：
|
Model |
O |
Eyepiece |
|||||||
|
SWH10X |
SWF15X |
SWF20X |
SWF30X |
||||||
|
M |
V |
M |
V |
M |
V |
M |
V |
||
|
TM-12 |
1X |
10X |
Φ23 |
15X |
Φ17 |
20X |
Φ14 |
30X |
Φ9 |
|
TM-13 |
1X |
10X |
Φ23 |
15X |
Φ17 |
20X |
Φ14 |
30X |
Φ9 |
|
TMS124 |
2X |
20X |
Φ11.5 |
30X |
Φ8.5 |
40X |
Φ7 |
60X |
Φ4.5 |
