ZSA300 Series Stereo Microscope Standard Outfits

(Zoom Range:0.7~5X/WD129.5mm )

Order No.

Item

ZSA301

ZSA302

ZSA303

8T1a

Main Body / Mount Dia. Ø80mm



18T

Main Body / /Mount Dia. Ø80mm





ES10

Wide Field Eyepiece WF10X/22mm

●●

●●

●●

ES15

Wide Field Eyepiece WF15X/16mm

○○

○○

○○

ES20

Wide Field Eyepiece WF20X/13mm

○○

○○

○○

ES25

Wide Field Eyepiece WF25X/9mm

○○

○○

○○

ES30

Wide Field Eyepiece WF30X/7mm

○○

○○

○○

18T.4

0.5x Big Objective

18T.5

1.5x Big Objective

18T.6

2x Big Objective

18T

Binocular Head / Inclined 30°





18TA

Trinocular Head / Inclined 30°





 18TB

Binocular Head / Inclined 30°







White and Black Plastic Stage / Ø95mm

Ground Glass Stage / Ø95mm

TV12

CCD TV Attachment







Halogen Tungsten Lamp 6V15W (Inclined Illumination)



Fluorescent Lamp 220V7W (Transmission Illumination)



Halogen Tungsten Lamp 6V20W (Transmission Illumination)

Halogen Tungsten Lamp 6V30W(Ribbon with Coaxial illumination)





Input: AC220V/50Hz Fuse Tube Ø5×20 2A







Note: “●” in the table is standard attachment. “○” is optional accessories.

Design change: To keep pace with technological advances, we have reserved the right to make design modification and changes without notice.
