Microscope MIC-W12A
By optical zoom, comparison microscope is used for macro of micro comparison of two or more objects in cutting or overlapping view field through one group of eyepieces observing left and right objective view fields. As clear imaging, high resolution, so you can identify the small differences.
Technical Parameters of Digital Microscope MIC-W12A
|
Digital Video Recording System |
|
Digital signal: 1024X768 pixels |
|
Analog signal: colored 480 lines, black and white 600 lines |
|
Easy to use, no other conversion devices, into monitor AV interface, computer USB interface or digital camera interface, presetting image processing software of user friendly, software with higher functions are of optional |
|
Optical Microscopy System |
|
Optical magnification range: 1.7X~255X; bridge body magnification ratio: 1.3X |
|
Eyepieces: WF10X22mm(WF6.3X28mm, WF20X14mmare for optional) |
|
Objectives: 0.7X~4.8X focusing, focusing ratio is 1:7 (0.3X, 2X objectives are for optional) |
|
IPD adjusting range: 60~75mm; working distance: 45~265mm |
|
Photographing, video recording interface magnification ratio: 0.5X |
|
Electric working objective stage: dimension: 180mmX180mm; moving range: X/51mm, Y/51mm, Z/54mm |
|
Horizontal electric linkage range:45mm; bridge body electric lifting range:70mm |
|
Illumination (2 groups): 12V50W halogen, adjustable, fan-cooled strong light source, 24V150W optic fiber cold light source |
|
Power supply: 220V AC input, 12V/24V DC output, accords with international safety standard |
|
Optional: WF6.3X28mm, WF20X14mmwide angle eyepieces; 0.3X, 2X additional objectives; digital camera interface; high power LED multi-wave band illuminating light source; ultraviolet excitation, IR receiving 6 band documentation attachment; bullet (warhead, cartridge case) traces expansion instrument; professional forensic image processing software |
