Camera Sensor

MN34120PA

16MP

Resolution @frame rate

4632x3488@8, 1080P@60, 720P@60

Pixels Size

1.335UM*1.335UM

Digital output

16bit

YUV422

Output format

YUV422

YUYV

Topography

ROI

image dioposale

GAMMA,LUT, saturation,acutance

Electronic shutter(us)

20-100000(full resolution), stepper:1

Auto, manual

Gains(dB)

0-36,stepper:0.1

Auto, manual

White balance(dB)

0-12,stepper:0.1

Auto, manual

Gamma coefficient

0.5~4.00

Digital interface

USB3.0

GPIO

8PIN,HIROSE HR25:PWR,1xOPI,1xOPO,BIOx2

IO support function mapping

Trigger

External trigger/software trigger

Power supply

DC5V,<4.5W, GPIO/USB

Lens interface

C

Dimension (mm)

--

Camera control model

driving model

Free drive

Working temperature

0-50
