Item

MIC-1000i

Order No

MIC-1000i Frame, One-piece construction from arm to base.

●

MIC-1000i

UCIS Infinity Independent Achromatic Optical Design

●

110/220V，50/60Hz

●

Coaxial coarse and fine focusing knob, height adjustable.

●

Condenser Adjust Unit

●

Head

Binocular Tube, Interpupillary distance 52-76mm, 30°inclined,360° rotatable, double diopter adjustable.

●

M1002i

Trinocular Tube, Interpupillary distance 52-76mm,30°inclined, 360° rotatable double diopter adjustable.

○

M1003i

Plan

Eyepiece

WF10X/20, High eye-point up to21mm.

●●

E1020PA

WF10X/22, High eye-point up to21mm.

○○

E1022PC

WF16X/14

○○

E1614WB

WF10X/20(Pointer), High eye-point up to21mm.

○

E1020GA

WF10X/22(Pointer), High eye-point up to21mm.

○

E1022GC

Reticule Eyepiece: CROSSWF10X/20

○

E1020RA

Reticule Eyepiece: CROSSWF10X/22

○

E1022RC

Centering Telescope

CTE

○

CTE

Infinity

Plan

Objectives

Plan 2X/0.06 ∞/-, WD3.55

○

WB-P4A

Plan 4X/0.10 ∞/-,WD12.31

●

WB-P4C

Plan 10X/0.25 ∞/0.17,WD5.03

●

WB-P10C

Plan 20X/0.40 ∞/0.17,WD2.71

○

WB-P20C

Plan 40X/0.65 ∞/0.17, WD0.72 (Spring)

●

WB-P40C

Plan 60X/0.80 ∞/0.17, WD0.69 (Spring)

○

WB-P60C

Plan 100X/1.25 ∞/0.17, WD0.17 (Spring,Oil)

●

WB-P100C

Plan 100X/1.0 ∞/0.17, WD 0.137 (water objective)

○

WB-P100CW

Plan 100X/0.8 ∞/0.17, WD 0.148 (dry objective)

○

WB-P100CD

Infinity

Plan

Phase-

Contrast

(positive or

negative)

Objectives

PH Plan 10X/0.25 ∞/0.17,WD5.03

○

WB-PPHp10C/WB-PPHn10C

PH Plan 20X/0.40 ∞/0.17,WD2.71

○

WB-PPHp20C/WB-PPHn20C

PH Plan 40X/0.65 ∞/0.17,WD0.72

(Spring)

○

WB-PPHp40C/WB-PPHn40C

PH Plan 60X/0.80 ∞/0.17, WD0.69

(Spring)

○

WB-PPHp60C/WB-PPHn60C

PH Plan 100X/1.25 ∞/0.17,WD0.17 (Spring,Oil)

○

WB-PPHp100C/WB-PPHn100C

Phase-

Contrast

Slide

10X PH

○

PCB-PPH10C

20X PH

○

PCB-PPH20C

40X PH

○

PCB-PPH40C

60X PH

○

PCB-PPH60C

100X PH

○

PCB-PPH100C

Condenser

Multi-Purpose Phase-contrast Condenser:

NA:1.25,Phase-contrast observation from

10X to 100X and Dark-field observation

from 10X to 40X is allowed

○

JG40

Abbe condenser: NA 1.25, with iris

diaphragm, with socket to accommodate

PH-slide. Condenser center adjustable,

color-coded diaphragm scale markings

correspondent with the objectives

of different powers.

●

JG3

Dark Condenser(Dry)

○

JG10

Stage

Double Mechanical Stage: super big 216x150mmplatform, with X/Y travel of 75x55mm by low-

Positioned X/Y coaxial control knob,

with scale mark and specimen-slide clip,

enough space to hold 2 specimen-slide.

●

ZT2

Rackless Mechanical Stage: 179(205)x

175mm platform, with X/Y travel of

75x50mmby low-positioned X/Y

coaxial control knob, with scale mark

and specimen-slide clip, enough space

to hold 2 specimen-slide.

○

ZT2A

Revolving

Nosepiece

quadruple, inward facing.

●

ZQ480

quintuple, inward facing

○

ZQ580

Illumination Kohler, With field diaphragm

●

KL3A

Electrical

Parts

For 6V/20W Halogen Bulb： Input: 100-

240V～0.5A, 47-63Hz, Output:6V3.4A,

Fuse:3.15A, 250V, F ф5×20mm, Halogen

Bulb Socket: G4

○

DQ3

For 6V/30WHalogen Bulb： Input: 100-

240V～0.5A, 47-63Hz, Output:6V3.4A,

Fuse:3.15A, 250V, F ф5×20mm, Halogen

Bulb Socket: G4

○

DQ2A

For 3W LED Bulb

●

DQL1

C-Mount

1X

○

SX3

0.5X

○

SX2

0.25X

○

SX4

Digital Camera Adapter

SD2

○

SD2

Digital

Camera Joint

(Please advice your digital

camera model in advance)

○

SDK

Filter

Blue

●

LA2-0011

Green

●

LU2-0011

Yellow

●

LH2-0011

Grass Glass

○

LB2-0011

Filter

Holder

Filter Holder: (Attached to the Kohler)

for more than one filter.

●

LA1-0071

Polarization

kits

Analyzer Slide

○

PQ1

Polarizer Slide

○

PY1

Reflected

Fluorescence

Attachment

DC Hg Florescence Lamp house 100W

○

DYX3

Mercury lamp 100W(Made in China)

○

BZ-0022H

Mercury lamp 100W(Osram)

○

BZ0022I

Filter Turret

○

LSS2 & LST1

UV Shield

○

LST1-5000

DC Hg Power Source House 100W

○

DYX3

UV Excitation Filter (I Grade)

○

YGMKI-UV

V Excitation Filter (I-Grade)

○

YGMKI-V

B Excitation Filter (I-Grade)

○

YGMKI-B

G Excitation Filter (I-Grade)

○

YGMKI-G

UV Excitation Filter (C-Grade)

○

YGMKC-UV

V Excitation Filter (C-Grade)

○

YGMKC-V

B Excitation Filter (C-Grade)

○

YGMKC-B

G Excitation Filter (C-Grade)

○

YGMKC-G

Illumination

Bulb

6V20W Osram Halogen Bulb

○

BZ-0022A

6V30W Osram Halogen Bulb

○

BZ-0022B

3W LED Bulb (out fixed Kohler illumination)

●

DQL1-1000

Immerse Oil

8ml

●

BZ-0027

Allen Screw Driver

φ2mm

●

BZ2-0018

Power Line

1.8m, CE certified

●

BZ-0021

Package

Inner package: foam, plastic bag;

Out Package: Carton

●

BZ3-0011A
