1. Super quality fluorescent filter. Can support six group fluorescent exciter, super image for multiple stained sample
2. Customized control system: focus system can be customized according to customer’s need, can be fixed on both left side or right side.
3. Brightness auto control: when changing to different objectives, auto brightness control, long term LED light, uniform brightness with easy management
4. Sapphire surface(abrasion forever resistance), mechanical stage, super anti-abrasion, Gorilla glass surface stage is optional
5. One click for photography: Press on the button in the base make digital photography completed.
6. Titling trinocular head (0°-35°)，beam splitting bar can be fixed on each side of the trinocular head.
7. Inner fixed control panel: users can customized any button to be connected to certain objective, after this setting, one press will lead automatic zoom change to that certain objective.
8. Objective automatic alteration: this machine is with auto mag. change and brightness auto adjustment function, this is the perfect instrument for users who needs to change mag. frequently. Meanwhile, users can customize two objectives for auto alteration.
9. Automatic condenser:can swing out the top lens according to the mag. change, ergonomic design for your use
10. Super high precision
New coating technology makes better transmission rate for capturing every details of fluorescence light.
Specification:
|
Optical system |
Infinity color corrected optical system |
|
|
Viewing head |
Ergonomic design tilting head, 0°-35°, interpupillary adjustable distance: 47-78mm; |
|
|
30° inclined binocular head; 360° rotatable; interpupillary adjustable distance: 47-78mm ; |
||
|
30° inclined trinocular head, splitting ratio R:T=50:50; 360° rotatable; interpupillary adjustable distance: 47-78mm |
||
|
Eyepiece |
High eye-point wide field plan eyepiece PL10x22mm, reticle or cross line Super wide SW10X/25mm eyepiece reticle or cross line High eye-point wide field plan eyepiece EW12.5X/17.5mm reticle or cross line High eye-point wide field plan eyepiece WF15X/16mm reticle or cross line High eye-point wide field plan eyepiece WF20X/12mm reticle or cross line |
|
|
Objective |
Infinity plan achromatic objectives (2X,4X,10X,20X,40X,100X) |
|
|
Infinity plan phase contrast objectives (10X,20X,40X,100X) |
||
|
Infinity plan fluorescence objectives (4X,10X,20X,40X,100X) |
||
|
Nosepiece |
Automatic sextuple nosepiece |
|
|
Body |
Coaxial focus system with upper limited and tension adjustment; coarse range: 30mm; fine precision: 0.002mm; focus height adjustable. |
|
|
Stage |
190x152mm double layer mechanical stage, sapphire surface, super anti-corrosive and anti-friction,moving range 78x32mm (left of right side hand wheel) precision : 0.1mm.(Gorilla glass surface stage is optional) |
|
|
Condenser |
automatic swing-out type N.A.0.9/0.25 condenser N.A.1.2/0.22 swing-out type achromatic condenser N.A.1.25 quintuple phase contrast condenser N.A.0.9 dry dark field condenser N.A.1.25 oil dark field condenser. |
|
|
Reflected fluorescence illumination system |
reflected fluorescence Koehler illumination with alterable field diaphragm and aperture diaphragm (center adjustable). Sixtuple fluorescent filter disc |
|
|
100HG mercury lamp house with viewfinder; the center and focal length of viewfinder &filament are adjustable. |
||
|
Transmitted illumination system |
Wide voltage: 100-240V, built-in transmitted Koehler illumination; 6V/30W halogen or 3W LED, pre-centered, intensity adjustable. |
|
|
Filter |
Yellow, green, blue, neutral filter |
|
|
Camera adapter |
0.5xCTV, 0.67xCTV, 1xCTV |
|
