MIC-Y series cameras are our new generation USB2.0 cameras (without built-in buffer).It makes dramatic break through in image transmission speed and color reproduction etc compared with first generation Y series cameras.Plug and play USB2.0 interface, occupy less system resources.
|
Model No |
Sensor |
Sensor |
Color |
Sensor |
Pixel |
Shutter |
Pixel |
Resolution |
Data |
Frame |
Lens |
|
Y130ME |
CMOS |
MT9M001 |
Mono |
1/2” |
5.2μm |
Rolling |
1.3MP |
1280 x 1024 |
USB2.0 |
29.6FPS |
C/ CS |
|
Y500ME |
CMOS |
MT9P031 |
Mono |
1/2.5” |
2.2μm |
Rolling |
5MP |
2592 x 1944 |
USB2.0 |
8.8FPS |
C/ CS |
|
Y300E |
CMOS |
MT9T001 |
Color |
1/2” |
3.2μm |
Rolling |
3MP |
2048 x 1536 |
USB2.0 |
10.5FPS |
C/ CS |
|
Y501E |
CMOS |
MT9P001 |
Color |
1/2.5” |
2.2μm |
Rolling |
5MP |
2592 x 1944 |
USB2.0 |
6FPS |
C/ CS |
|
Y1000E |
CMOS |
MT9J003 |
Color |
1/2.3” |
1.67μm |
Rolling |
10MP |
3664 x 2748 |
USB2.0 |
3.2FPS |
C/ CS |
|
Model No |
Y130ME-H |
|
SENSOR |
MT9M001 |
|
SENSOR Size |
6.66mm(H) X 5.32mm(V) / 1/2" CMOS Monochrome |
|
Effective Pixel |
1280*1024(1.3M) |
|
Scan Mode |
Progressive scanning |
|
Resolution/ Frame Rate |
1280*1024(ROI) ：29.6FPS |
|
1024*768(ROI) ：44FPS |
|
|
640*512(ROI) ：90FPS |
|
|
640*512(SUM2) ：29.6FPS |
|
|
320*256(ROI) ：253FPS |
|
|
320*240(ROI) ：268FPS |
|
|
Any area ROI |
|
|
Pixel Size |
5.2μm*5.2μm |
|
Image Data Format |
8bit Raw Data |
|
Sensitivity |
2.1V/Lux-sec |
|
SNR |
45 dB |
|
Dynamic Range |
68.2 dB |
|
Definition |
800 Line |
|
spectral response |
380nm-1000nm |
|
Shutter |
Rolling Shutter |
|
Exposure Time |
0.028ms - 262ms |
|
Exposure Control |
Manual / Auto / Area |
|
Product Firmware Update |
Support Remote Update |
|
Picture Format |
RAW,BMP,JPG,PNG |
|
Programmable Control |
Camera operating speed, Image Size,Photograph Mode, image brightness, Exposure Time,Gain, anti-strobe, GAMMA,Contrast , Black Balance, Sharpness,Noise Reduction,3D Noise Reduction |
|
Operating System |
Windows |
|
Software Interface |
TWAIN，DirectShow |
|
Data Interface |
USB2.0(B type interface) |
|
LED Pilot Light |
Lighting Once Plug/ Flashing When Working |
|
Rated Power |
>1.5W |
|
Power Supply |
USB5V（Without external power supply circuit） |
|
Working Temperature |
0℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Working Humidity |
10%-90%RH（No condensation） |
|
Storage Humidity |
10%-60%RH |
|
Lens Mount |
C/CS Mount |
|
Dimension |
45*48*37.4mm(exclude extended ring and external fixed block) |
|
Weight |
112g(include shell and fixed block) |
|
Model No |
Y500ME-H |
|
SENSOR |
MT9P031 |
|
SENSOR Size |
5.7mm(H) X 4.28mm(V) / 1/2.5" CMOS Monochrome |
|
Effective Pixel |
2592*1944（5M） |
|
Scan Mode |
Progressive scanning |
|
Resolution/ Frame Rate |
2592*1944：8.8FPS |
|
2048*1536（ROI）：13FPS |
|
|
1920*1080（ROI）：19.5FPS |
|
|
1280*960（SUM）：22FPS |
|
|
640*480（SUM）：34.5FPS |
|
|
1280*960（BIN）：22FPS |
|
|
640*480（BIN）：34.5FPS |
|
|
Any area ROI |
|
|
Pixel Size |
2.2μm*2.2μm |
|
Image Data Format |
8bit Raw Data |
|
Sensitivity |
1.4V/Lux-sec(550nm) |
|
SNR |
38.1 dB |
|
Dynamic Range |
70.1 dB |
|
Definition |
1200-1300 Line |
|
Spectral Response |
380nm-1000nm |
|
Shutter |
Rolling Shutter |
|
Exposure Time |
0.058ms -3000ms |
|
Exposure Control |
Manual / Auto / Area |
|
Product Firmware Update |
Support Remote Update |
|
Picture Format |
RAW,BMP,JPG,PNG |
|
Programmable Control |
Camera operating speed, Image Size,Photograph Mode, image brightness,Exposure Time,Gain, anti-strobe GAMMA,Contrast , Black Balance,Sharpness,Noise Reduction,3D Noise Reduction |
|
Operating System |
Windows |
|
Software Interface |
TWAIN，DirectShow |
|
Data Interface |
USB2.0(B type interface) |
|
LED Pilot Light |
Lighting Once Plug/ Flashing When Working |
|
Rated Power |
>1.5W |
|
Power Supply |
USB5V（Without external power supply circuit） |
|
Working Temperature |
0℃~50℃ |
|
Storage Temperature |
-20℃~60℃ |
|
Working Humidity |
10%-90%RH（No condensation） |
|
Storage Humidity |
10%-60%RH |
|
Lens Mount |
C/CS Mount |
|
Dimension |
45*48*36.9mm(exclude extended ring and external fixed block) |
|
Weight |
112g(include shell and fixed block) |
|
Model |
Y300E-H |
|
Pixels |
3.0 MP（Color） |
|
Sensor Model |
MT9T001 |
|
Sensor Size |
6.55mm(H)x4.92mm(V) 1/2" |
|
Pixel Size |
3.2μm x 3.2μm |
|
Resolution/ |
2048 x 1536（full resolution）：10.5FPS |
|
1920 x 1080（ROI）：15.4FPS |
|
|
1024 x 768（ROI）：31.5FPS |
|
|
1024 x 768（2x2BIN）：26.6FPS |
|
|
640 x 480（ROI）：60.6FPS |
|
|
_ |
|
|
Spectral |
|
|
Exposure |
25μs ～ 3000ms |
|
Sensitivity |
>1.0V/Lux-sec |
|
Shutter |
Electronic Rolling Shutter |
|
Image Data Format |
8bit RAW format |
|
Operating Mode |
Continuous output |
|
Scanning Mode |
Progressive Scan |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area |
|
Image Processing |
GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction / Sharpness/ saturation |
|
Picture Format |
JPEG / BMP / PNG / RAW |
|
Product ID |
User Defined |
|
Software Interface |
DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) |
|
Data Interface |
USB2.0 (B Type interface) |
|
Lens Mount |
C/CS Mount |
|
Dimension |
45mm x 48mm x 36.4mm（Exclude lens mount） |
|
dPCB Size |
39mm x 39mm （2 pcs board） |
|
Weight |
Approx. 112g （with case and fixed blocks） |
|
Rotated Voltage |
USB5V power supply（No external power supply circuit） |
|
Rated power |
＜ 1.5W |
|
Temperature |
operation ：0～50℃ / storage：-20℃～60℃ |
|
Humidity |
Working ：10%～90%RH（No condensation） / Storage：10%～60%RH |
|
LED Pilot Light |
Lighting once plug/ flashing when working |
|
Model |
Y501E-H |
|
Pixels |
5.0 MP（Color） |
|
Sensor Model |
MT9P001 |
|
Sensor Size |
5.7mm(H)x4.28mm(V) 1/2.5" |
|
Pixel Size |
2.2μm x 2.2μm |
|
Resolution/ |
2592 x 1944（full resolution）：6FPS |
|
2048 x 1536（ROI）：9FPS |
|
|
1920 x 1080（ROI）：13.4FPS |
|
|
1280 x 960（SUM）：15FPS |
|
|
1280 x 960（BIN）：15FPS |
|
|
640 x 480（SUM）：23.7FPS |
|
|
640 x 480（BIN）：23.7FPS |
|
|
Any Area（ROI） |
|
|
Spectral |
380nm ～ 650nm |
|
Exposure |
86μs ～ 3000ms |
|
Sensitivity |
1.4V/Lux-sec |
|
Shutter |
Electronic Rolling Shutter |
|
Image Data Format |
8bit RAW format |
|
Operating Mode |
Continuous output |
|
Scanning Mode |
Progressive Scan |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area |
|
Image Processing |
GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction / Sharpness/ saturation |
|
Picture Format |
JPEG / BMP / PNG / RAW |
|
Product ID |
User Defined |
|
Software Interface |
DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) |
|
Data Interface |
USB2.0 (B Type interface) |
|
Lens Mount |
C/CS Mount |
|
Dimension |
45mm x 48mm x 36.4mm（Exclude lens mount） |
|
PCB Size |
39mm x 39mm （2 pcs board） |
|
Weight |
Approx. 112g （with case and fixed blocks） |
|
Rotated Voltage |
USB5V power supply（No external power supply circuit） |
|
Rated power |
＜ 1.5W |
|
Temperature |
operation ：0～50℃ / storage：-20℃～60℃ |
|
Humidity |
Working ：10%～90%RH（No condensation） / Storage：10%～60%RH |
|
LED Pilot Light |
Lighting once plug/ flashing when working |
|
Model |
Y1000E-H |
|
Pixels |
10 MP（Color） |
|
Sensor Model |
MT9J003 |
|
Sensor Size |
6.44mm(H)x4.616mm(V) 1/2.3" |
|
Pixel Size |
1.67μm x 1.67μm |
|
Resolution/ |
3664 x 2748（full resolution）：3.2FPS |
|
2592 x 1944（ROI）：6.1FPS |
|
|
1920 x 1080（ROI）：13.7FPS |
|
|
1600 x 1200（BIN）：11.1FPS |
|
|
1280 x 720（BIN）：17.3FPS |
|
|
1024 x 768（ROI）：19FPS |
|
|
800 x 600（BIN）：20FPS |
|
|
|
|
|
Spectral |
380nm ～ 650nm |
|
Exposure |
95μs ～ 3000ms |
|
Sensitivity |
0.31V/Lux-sec |
|
Shutter |
Electronic Rolling Shutter |
|
Image Data Format |
8bit RAW format |
|
Operating Mode |
Continuous output |
|
Scanning Mode |
Progressive Scan |
|
Exposure |
Manual / Auto / Area |
|
White Balance |
Manual / One-Time / Auto / Area |
|
Image Processing |
GAMMA / Contrast / Black Level / Noise Reduction / 3D Noise Reduction / Sharpness/ saturation |
|
Picture Format |
JPEG / BMP / PNG / RAW |
|
Product ID |
User Defined |
|
Software Interface |
DirectShow / TWAIN |
|
Operating System |
Windows XP(32 bit) / Windows7(32 bit/64 bit) / Windows8(32 bit/64 bit) |
|
Data Interface |
USB2.0 (B Type interface) |
|
Lens Mount |
C/CS Mount |
|
Dimension |
45mm x 48mm x 36.4mm（Exclude lens mount） |
|
PCB Size |
39mm x 39mm （2 pcs board） |
|
Weight |
Approx. 112g （with case and fixed blocks） |
|
Rotated Voltage |
USB5V power supply（No external power supply circuit） |
|
Rated power |
＜ 1.5W |
|
Temperature |
operation ：0～50℃ / storage：-20℃～60℃ |
|
Humidity |
Working ：10%～90%RH（No condensation） / Storage：10%～60%RH |
|
LED Pilot Light |
Lighting once plug/ flashing when working |
