U500M |
CMOS |
MT9P031 |
Mono |
1/2.5” |
2.2μm |
Rolling |
5MP |
2592 x 1944 |
USB3.0 |
14FPS |
C/ CS |
|
U501 |
CMOS |
MT9P006 |
Color |
1/2.5” |
2.2μm |
Rolling |
5MP |
2592 x 1944 |
USB3.0 |
14FPS |
C/ CS |
|
U1401 |
CMOS |
MT9F002 |
Color |
1/2.3” |
1.4μm |
Rolling |
14MP |
4384 x 3288 |
USB3.0 |
11FPS |
C/ CS |
|
Model No |
U500M-H |
|
Pixel |
5MP (Mono) |
|
Sensor |
MT9P031 |
|
Sensor Size |
5.70mm(H) x 4.28mm(V) 1/2.5" |
|
Pixel Size |
2.2μm x 2.2μm |
|
Resolution/Frame rate |
2592 x 1944（Full resolution）：14FPS |
|
1920 x 1080（ROI）：30FPS |
|
|
1024 x 768（ROI）：45FPS |
|
|
1280 x 960（SU）：36FPS |
|
|
1280 x 960（BIN）：36FPS |
|
|
640 x 480（SU）：55FPS |
|
|
640 x 480（BIN）：55FPS |
|
|
_ |
|
|
Sensitivity |
1.4V/Lux-sec |
|
Spectral Range (nm) |
380nm ～ 1100nm |
|
Exposure Time |
109μs ～ 3000ms |
|
Working Mode |
Continous output |
|
Hardware trigger interface |
_ |
|
Shutter Type |
Electronic Rolling Shutter |
|
Image data format |
8bit/10bit/12bit RAW format |
|
White Balance Function |
Manual/One-time /Automatic/Area(only for color camera) |
|
Image processing |
GAMMA / Contrast / Black level /Reduce noise / 3D reduce noise / Sharpness /Saturation(only for color camera) |
|
UVC Standard |
Not support |
|
Scan type |
Progressive Scan |
|
Built-in Buffer |
64MB |
|
Exposure Function |
MF / AE / Area Exposure |
|
Photo Format |
JPEG / BMP / PNG / RAW |
|
Product ID |
User-defined |
|
Software Interface |
DirectShow / TWAIN / UVC |
|
Systems |
Windows XP(32bit) / Windows7(32bit/64bit) / Windows8(32bit/64bit) |
|
Data Interface |
USB3.0 （B type interface） |
|
lense Mount |
C / CS Mount |
|
Product Size (mm) |
59.7mm x 45mm x 35mm（Exclude lense interface） |
|
Voltage(V) |
USB 5V（No external power supply circuit） |
|
Power(W) |
≤ 4W |
|
Weight |
Approx 125g |
|
Temperature |
Working：0～45℃ / Storage：-20℃～60℃ |
|
HUidity |
Working：10%～90%RH（No condensation）/ Storage：10%～60%RH |
|
LED pilot Light |
Lighting once plug/ flashing when working |
|
Model No |
U501-H |
|
|
Pixel |
5MP (Color) |
|
|
Sensor |
MT9P006 |
|
|
Sensor Size |
5.70mm(H) x 4.28mm(V) 1/2.5" |
|
|
Pixel Size |
2.2μm x 2.2μm |
|
|
Resolution/Frame rate |
2592 x 1944（Full resolution）：14FPS |
|
|
1920 x 1080（ROI）：30FPS |
||
|
1024 x 768（ROI）：45FPS |
||
|
1280 x 960（SU）：36FPS |
||
|
1280 x 960（BIN）：36FPS |
||
|
640 x 480（SU）：55FPS |
||
|
640 x 480（BIN）：55FPS |
||
|
- |
||
|
Sensitivity |
||
|
380nm ～ 650nm |
1.76V/Lux-sec |
|
|
Spectral Range (nm) |
109μs ～ 3000ms |
|
|
Exposure Time |
Continous output |
|
|
Working Mode |
_ |
|
|
Hardware trigger interface |
Electronic Rolling Shutter |
|
|
Shutter Type |
8bit/10bit/12bit RAW format |
|
|
Image data format |
Manual/One-time /Automatic/Area(only for color camera) |
|
|
White Balance Function |
GAMMA / Contrast / Black level /Reduce noise / 3D reduce noise / Sharpness /Saturation(only for color camera) |
|
|
Image processing |
Support |
|
|
UVC Standard |
Progressive Scan |
|
|
Scan type |
64MB |
|
|
Built-in Buffer |
MF / AE / Area Exposure |
|
|
Exposure Function |
JPEG / BMP / PNG / RAW |
|
|
Photo Format |
User-defined |
|
|
Product ID |
DirectShow / TWAIN / UVC |
|
|
Software Interface |
Windows XP(32bit) / Windows7(32bit/64bit) / Windows8(32bit/64bit) |
|
|
Systems |
USB3.0 （B type interface） |
|
|
Data Interface |
C / CS Mount |
|
|
lense Mount |
59.7mm x 45mm x 35mm（Exclude lense interface） |
|
|
Product Size (mm) |
USB 5V（No external power supply circuit） |
|
|
Voltage(V) |
≤ 4W |
|
|
Power(W) |
Approx 125g |
|
|
Weight |
Working：0～45℃ / Storage：-20℃～60℃ |
|
|
Temperature |
Working：10%～90%RH（No condensation） / Storage：10%～60%RH |
|
|
HUidity |
Lighting once plug/ flashing when working |
|
|
LED pilot Light |
|
|
|
Model |
UN1401-H2 |
|
Pixels |
14MP (Color) |
|
Sensor |
MT9F002 |
|
Sensor Size |
1/2.3" |
|
Photosurface Size |
6.138mm(H) x4.603 mm (V) |
|
Pixel Size |
1.4μm x 1.4μm |
|
Resolution/Frame rate |
4384 x 3288 (Full resolution)：11.25FPS |
|
4096 x 2160 (ROI)：18FPS |
|
|
2592 x 1944 (ROI)：30FPS |
|
|
1920 x 1080 (BIN) ：36FPS |
|
|
Any Area (ROI) |
|
|
Shutter |
Rolling Shutter / Global Reset Release |
|
Exposure Time |
78μs ~ 6000ms |
|
Sensitivity |
0.724V/Lux-sec |
|
Spectral Range |
380nm~650nm (With infrared filter) |
|
SNR |
35.5db |
|
Dynamic Range |
65.3dB |
|
Operating Mode |
Continous output/software trigger |
|
Scan type |
Progressive Scan |
|
Exposure |
Manual/ Auto / Area Exposure |
|
White Balance |
Manual/One-time /Auto/Area |
|
Image processing |
GAMMA / Contrast / RGB Gain / Black level /Reduce noise / 3D reduce noise / Sharpness /Saturation |
|
Image data format |
8bit/10bit/12bit RAW format |
|
Photo Format |
JPEG / BMP / PNG / RAW |
|
Built-in Buffer |
64MB |
|
Product ID |
User-defined |
|
Software Interface |
DirectShow / TWAIN |
|
Operating Systems |
Windows XP(32bit) / Windows7(32bit/64bit) / Windows8(32bit/64bit) / Windows8.1(32bit/64bit) / Windows10(64bit） |
|
Data Interface |
USB3.0 (Type-B) |
|
lense Mount |
C Mount |
|
Dimension (mm) |
54.8mm x 45mm x 35mm (Exclude lense interface) |
|
Rated Voltage(V) |
USB 5V (No external power supply circuit) |
|
Rated Power(W) |
< 4W |
|
Weight |
Approx 125g |
|
Temperature |
Working：0～40℃ / Storage：-20℃～60℃ |
|
HUidity |
Working：10%～90%RH (No condensation) / Storage：10%～60%RH |
|
LED pilot Light |
Lighting once plug/ flashing when working |
