Items

Specification

O-M1-300

O-M1-500

Eyepiece

WF10×-20 mm

●●

●●

WF5×

○○

○○

WF12.5×

○○

○○

WF16×

○○

○○

WF10×-18 mm(Reticule0.1mm)

○

○

Non-stress Infinity Plan Objective

4×/0.10 W.D=27.24mm

●

●

10×/0.25 W.D=18.48mm

●

●

20×/0.40 W.D=8.35mm

●

●

40×/0.65 (S) W.D=3.90mm

●

●

50×/0.70 (S) W.D=1.95mm

○

○

80×/0.80 (S) W.D=0.85mm

○

○

Infinity Plan Objective

20×/0.40 (S) W.D=2.14mm

○

○

40×/0.65 (S) W.D=0.15mm

○

○

100×/1.25(Oil) (S) W.D=0123mm

○

●

Seidentopf Binocular Head

Inclined 30°,Rotatable 360°, Interpupilary Distance: 50-75mm

●

●

Seidentopf Trinocular Head

Inclined 30°, Rotatable 360°, Interpupilary Distance: 50-75mm.--- Light Distribution: 0:100

○

○

Nosepiece

Quintuple

●

●

Mechanical Stage For Reflection Illumination System

Stage Size:190×140mmTravel:78mm×55mmCoaxial Coarse and Fine Focusing Knobs

●

Mechanical Stage For Transmission Illumination System

Stage Size:190×140mmTravel:78mm×55mmCoaxial Coarse and Fine Focusing Knobs

●

Stage Plate

●

●

Clip

●

Glass Plate

○

Stage Micrometer

0.01mm

○

○

Polarizing Unit

Polarizing Slide Analyzer Slide

●

●

Condenser

Abbe N.A. 1.25(Iris Diaphragm)

●

Illumination

12V/50W Halogen Lamp  (Reflection Illumination System)

●

●

6V/20W Halogen Lamp  (Transmission Illumination System)

●

6V/30W Halogen Lamp

○

Field Diaphragm

●

Filter

Blue

●

Green

○

Yellow

○

C-mount

1×

○

○

0.5×

○

○
