Comparison Microscope MIC-W14A
By optical zoom, comparison microscope is used for macro of micro comparison of two or more objects in cutting or overlapping view field through one group of eyepieces observing left and right objective view fields. As clear imaging, high resolution, so you can identify the small differences.
Brief Introduction of Comparison Microscope MIC-W14A
Comparison microscope MIC-W14Ais a new generation of product developed by our company by having accumulated many years of experiences, fully absorbed essences at home and abroad, this product successfully solved the technical problems of comparing ridge width and consistency adjustable (this technology is included in the national technology security projects) and solved the problems that comparison ridge can rotate 360°while moving horizontally left and right, and binocular system dip adjustable, so the main technical performance of the comparison microscope reached the international advanced level.
MIC-W14Ais an upgraded product, which not only retains excellent technical performances of traditional products, but also increases its image quality and magnification, enlarges 10X and 20X eyepieces view field diameters, bridge body adopts with electronic lifting technology; and keeps linkage working stages, illumination and various accessories, and so on...inverted binocular observing system (located below the bridge body) makes the instrument shape, structure more beautiful, reasonable, reliable, more in line with ergonomic principles, and makes the instrument fully plays its functions of comparison and identification.
This product is an ideal instrument for public security, inspection, court on document retrieval, marks checking and school teaching (used for bullets, tool marks, fingerprints, seals, texts, coins comparison and identification), but also for industries and sectors such as banks, archaeology, electronics, biology, agriculture which need to identify on objects to use.
Accessories：
|
Linkage frame |
Tricolor LED light |
|
Objective lens and objective |
lens convertor |
|
Dip adjustable system |
CCD camera tube |
|
Link arm |
Moving screw |
|
Cold light source |
Rotary working stage |
|
Control panel |
|
Main Technical Parameters:
|
Optical magnification range: 5X~200X (includes optional units) |
|
Eyepieces: 10X/φ22 20X/φ12 (20X eyepiece is optional unit) |
|
Objective lens: 0.5X, 1X, 1.5X, 2X, 4X, 6X, 10X seven files in all |
|
Bridge body open file size:460mm |
|
IPD adjusting range: 60~75mm |
|
Working distance: 0.5X138mm, 10X49mmthe remaining100mm |
|
Objective stage size: 100X100mmmoving range: X50mmY50mmZ55mm |
|
Horizontal linkage (electronic) range:45mm |
|
Bridge body (electronic) lifting range:170mm |
|
Objective view field observing range: Φ1.2~Φ44mm(includes optional units) |
|
2 kinds of power supply: 24V150W optic fiber cold light source (unmarked in the picture), with optical lens, brightness and light spots adjustable, 4.5V~7.5V/5W LED light group (can provide for white, red, green, blue four tricolors); light source brightness high, cooling effect good, application range wide, and easy to use, long service life; |
|
Power supply: 220V AC input, 24V and 4.5V~7.5V DC output, accords with international safety standard |
