Polarizing microscope for normal inspection and education.
Widely used in petrology, geology, mineralogy, metallurgy, materiality and so on.
Specification
|
|
|
XJN-P5 |
|
Viewing Head |
Sliding binocular viewing head, Inclined at 45° |
● |
|
Sliding trinocular viewing head, Inclined at 45° |
○ |
|
|
Eyepiece |
Eyepiece WF10×/18 with scale of cross hair |
● |
|
Eyepiece WF10×/18 with reticule |
● |
|
|
Eyepiece WF 10×/18 |
● |
|
|
Objective |
Strain free achromatic objective 4×、10× |
● |
|
Strain free plan achromatic objective 25×、40×、63× |
● |
|
|
Lamp house adjustment objective |
○ |
|
|
Nosepiece |
Backward quadruple nosepiece, Center adjustable |
● |
|
Analyzer |
Rotatable analyzer with gradation 0°-90° |
● |
|
Bertrand Lens |
Bertrand lens, Sliding in/out of optical path |
● |
|
Optical Compensator |
λ Slip（First class red）, 1/ 4λ Slip, Quartz wedge |
● |
|
Revolving Round Stage |
Diameter Φ160mm, Graduated in 1°Increments, Minimum resolution 6' when using venire Scale |
● |
|
Focusing |
Coaxial coarse & fine adjustment, Range28mm, Fine division0.002mm |
● |
|
Illumination |
12V/ 50W Halogen lamp, Brightness adjustable |
● |
|
Accessories |
Mechanical stage, Moving rang 30×40mm |
● |
|
Specimen presser |
○ |
|
|
Micrometer |
● |
Note: “●” in the table is standard attachment. “○” is optional accessories.
Design change: To keep pace with technological
advances, we have reserved the right to
make design modification and changes
without notice.
