TNJ-17 Series is the zoom stereo microscopes, which can magnify at object to erecting image. It use the horizontal pair knob to vary the magnification, that make the operation very easy. The zoom objective of the main body is 0.63X-5X,the zoom ratio is 1:8.It can be equipped with 0.5X,1.5X,2 X auxiliary objectives and 10X,15X,20X wide field eyepieces. The trinocular zoom stereo microscope can configure CMOS digital camera eyepiece, photography CCD attachment or digital camera. This series microscopes have character of long working distance and sharp image. Extreme contrast, large depth of field and high resolution. It is suitable for viewing the 3D object in both natural &engineering fields, and widely used in Light industry and Electronic industry and Electronic industry. It can also be a standard outfit for education and scientific research department.
|
Specification |
Model |
|||||
|
TNJ-17 |
TNJ-17T |
TNJ-17A |
TNJ-17AT |
TNJ-17BT |
||
|
Viewing Head |
Binocular Head (55mm-75mm) |
● |
|
● |
|
|
|
Trinocular Head (55mm-75mm) |
|
● |
|
● |
● |
|
|
Eyepiece |
WF10X/23 |
● |
● |
● |
● |
● |
|
Objective |
Zoom range:0.63X- 5XZoom ratio:1:8 |
● |
● |
● |
● |
● |
|
Working Distance |
110mm |
● |
● |
● |
● |
● |
|
Illumination |
Upper illumination: incident Light Halogen bulb:12C15W AC85V-265V |
● |
● |
● |
● |
|
|
Nether illumination: Transmission Light Halogen bulb:12C15W AC85V-265V |
● |
● |
●
|
● |
|
|
|
Ring fluorescent lamp |
|
|
|
|
● |
|
|
Optional Accessory |
Eyepieces:WF10X/25 WF15X/17 WF20X12.5 Ring fluorescent lamp |
|||||
|
1.3Mega、2.0Mega、3.0Mega、5.0Megapixels CMOS |
||||||
|
Upper and nether LED light:12V/5W |
||||||
|
Auxiliary Objectives:0.5X 1.5X 2X |
||||||
|
Photograph attachment and CCD device 0.5X,2.57X,0.75X CCD |
||||||
|
Camera, color 1/3″High resolution 520TV lines |
||||||
|
Digital camera eyepiece |
||||||
