Optical microscopy system |
|
|
Optical magnification |
1X-240X |
|
Eyepiece |
10X/φ24mm 20X/φ13mm. High Eye point Wide Field Eyepiece |
|
Tilting binocular head |
0-30°；interpupillary distance 54-75mmadjustable. |
|
Objective(converter) |
0.5X、1X、2X、4X、6X、2X and 0.2X objective |
|
Electrical touch screen |
MIC-20 can operate left and right side single field of view, or make abutment, double image field of view; left&right side objective magnification change, left&right side illumination position, left&right side stage X-Y or back-front movement. And each step will be controlled and recorded by the computer system; this instrument can be operated with remote controller for comparison. |
|
Evidence acquisition |
Inner fixed3M CCD, front fixed20MDSLR camera |
|
LED light |
MIC-20 offers 8 bands light source: red 680nm、orange 580nm、yellow 560nm、green 510nm、cyan 450nm、blue 410nm、ultraviolet 390nm、white 10-680nm |
|
Inner fixed filter |
Infrared 850nm, orange 580nm, green 510nm, visible light 400-680nm, full spectrum 0------∞. |
|
Coaxial light |
45°refraction angle |
|
Polarizing light |
0-360° rotatable ；90° orthogonal |
|
Stage |
Moving range: back&front50mm, left&right55mm, automatic or manual 40+60mm |
|
Electric lift column |
moving range: 0-150mm. |
|
Working stage electric moving range：0-300mm. |
|
|
Bullet identification clamp diameter:φ6-18mm, the rifling mark：4-6 |
|
|
MIC-20 is with all kinds of warhead, shell case, lock, thread clamp, tool holder, magnetic stage, tiltboard, Bottom transparent table |
|
